Shell end mills
Smooth-edged
h ƍ
a ƍ
GG(G)
Rm Rm Rm
< 850 850-1100 1100-1300
UNICUT-4X
Coating Article-N°. ø-Code
Example: U3209
Order-N°. U 3209 110
Ø d 1 d 2 b
Code k8 H7 k13 z
110 40.00 16.00 32.00 8 •
130 50.00 22.00 36.00 8 • V
160 63.00 27.00 40.00 10 •
180 80.00 27.00 45.00 12 •
