Series A3 (continued)

.6299" - .7500"
(16.000mm - 19.050mm)

d1 † d2 l1 l2 r l3 d3 END MILLS HIGH PERFORMANCE
EDP# Diameter Shank Overall Flute Corner Reach Neck
Decimal Metric Diameter Length Length Radius Length Diameter
07126 .6299 16.000 16.0 100 24 - 50 15.40
07127 .6299 16.000 16.0 100 24 0.50 50 15.40
07128 .6299 16.000 16.0 100 24 1.00 50 15.40
NEW 07129 .6299 16.000 16.0 100 24 1.50 50 15.40
07130 .6299 16.000 16.0 100 24 3.00 50 15.40
NEW 07131 .6299 16.000 16.0 100 24 6.00 50 15.40
07132 .6299 16.000 16.0 100 32 - 50 15.40
07133 .6299 16.000 16.0 100 32 0.50 50 15.40
07134 .6299 16.000 16.0 100 32 1.00 50 15.40
07135 .6299 16.000 16.0 100 32 1.50 50 15.40
07136 .6299 16.000 16.0 100 32 3.00 50 15.40
NEW 07137 .6299 16.000 16.0 100 32 6.00 50 15.40 70 6
07138 .7500 3/4" 19.050 3/4" 4" 1-3/4" - - -
07139 .7500 3/4" 19.050 3/4" 4" 1-3/4" .015" - -
NEW 07140 .7500 3/4" 19.050 3/4" 4" 1-3/4" .030" - -
07141 .7500 3/4" 19.050 3/4" 4" 1-3/4" .060" - -
07142 .7500 3/4" 19.050 3/4" 4" 1-3/4" .078" - -
NEW 07143 .7500 3/4" 19.050 3/4" 4" 1-3/4" .094" - -
07144 .7500 3/4" 19.050 3/4" 4" 1-3/4" .120" - -
07145 .7500 3/4" 19.050 3/4" 4" 1-3/4" .156" - -
07146 .7500 3/4" 19.050 3/4" 4" 1-3/4" .190" - -
07147 .7500 3/4" 19.050 3/4" 4" 1-3/4" .250" - -
07148 .7500 3/4" 19.050 3/4" 4" 1-3/4" BALL - - MATERIAL HARDNESS (Rc)
07149 .7500 3/4" 19.050 3/4" 4" 1" - 2" .715"
07150 .7500 3/4" 19.050 3/4" 4" 1" .030" 2" .715"
07151 .7500 3/4" 19.050 3/4" 4" 1" .060" 2" .715"
07152 .7500 3/4" 19.050 3/4" 4" 1" .090" 2" .715"
07153 .7500 3/4" 19.050 3/4" 4" 1" .120" 2" .715"
07154 .7500 3/4" 19.050 3/4" 4" 1" .125" 2" .715"
NEW 07155 .7500 3/4" 19.050 3/4" 4" 1" .160" 2" .715"
NEW 07156 .7500 3/4" 19.050 3/4" 4" 1" .190" 2" .715"
NEW 07157 .7500 3/4" 19.050 3/4" 5" 2-1/4" - - -
07158 .7500 3/4" 19.050 3/4" 5" 2-1/4" .030" - - 35 6
07159 .7500 3/4" 19.050 3/4" 5" 2-1/4" .060" - -
07160 .7500 3/4" 19.050 3/4" 5" 2-1/4" .120" - -
07161 .7500 3/4" 19.050 3/4" 5" 2-1/4" .125" - -
07162 .7500 3/4" 19.050 3/4" 5" 2-1/4" .190" - -
07163 .7500 3/4" 19.050 3/4" 5" 2-1/4" .250" - -
NEW 07226 .7500 3/4" 19.050 3/4" 6" 3-1/4" - - -
07164 .7500 3/4" 19.050 3/4" 6" 1" - 3-3/8" .715"
07165 .7500 3/4" 19.050 3/4" 6" 1" .030" 3-3/8" .715"
07166 .7500 3/4" 19.050 3/4" 6" 1" .060" 3-3/8" .715"
07167 .7500 3/4" 19.050 3/4" 6" 1" .090" 3-3/8" .715"
07168 .7500 3/4" 19.050 3/4" 6" 1" .125" 3-3/8" .715"
07169 .7500 3/4" 19.050 3/4" 6" 1" .250" 3-3/8" .715"
07170 .7500 3/4" 19.050 3/4" 6" 1" BALL 3-3/8" .715"

0 6
continued ?
