Page 154 - GARR_TOOL(CATALOG_INT)

Series V5 (continued)

.5000"
HIGH PERFORMANCE END MILLS (plain) EDP# Decimal Diameter Metric Diameter Overall Length Corner Length Diameter
(12.700mm)

r
d1
†
d3
d2
l1
l2
l3
Shank
Reach
Flute
Neck
Radius
(weldon)
Length
-
50054
1/2"
.5000
1/2"
5/8"
50106
12.700
2-1/2"
50305
5/8"
.020"
2-1/2"
1/2"
1/2"
50055
12.700
.5000
50306
12.700
.5000
1/2"
50307
.030"
1/2"
50107 50304 .5000 1/2" 12.700 1/2" 2-1/2" 5/8" .010" - - - - - - - -
5/8"
2-1/2"
50056 50308 .5000 1/2" 12.700 1/2" 3" 1" - - -
50108 50309 .5000 1/2" 12.700 1/2" 3" 1" .010" - -
50057 50310 .5000 1/2" 12.700 1/2" 3" 1" .020" - -
50109 50311 .5000 1/2" 12.700 1/2" 3" 1" .030" - -
50058 50312 .5000 1/2" 12.700 1/2" 3" 1-1/4" - - -
50111 50313 .5000 1/2" 12.700 1/2" 3" 1-1/4" .010" - -
50059 50314 .5000 1/2" 12.700 1/2" 3" 1-1/4" .015" - -
70 50061 50315 .5000 1/2" 12.700 1/2" 3" 1-1/4" .020" - -
6
50062 50316 .5000 1/2" 12.700 1/2" 3" 1-1/4" .030" - -
50063 50317 .5000 1/2" 12.700 1/2" 3" 1-1/4" .045" - -
50064 50318 .5000 1/2" 12.700 1/2" 3" 1-1/4" .060" - -
50065 50319 .5000 1/2" 12.700 1/2" 3" 1-1/4" .090" - -
50433 50435 .5000 1/2" 12.700 1/2" 4" 1-1/2" .010" - -
51031 - .5000 1/2" 12.700 1/2" 4" 1-1/2" .015" - -
51032 - .5000 1/2" 12.700 1/2" 4" 1-1/2" .030" - -
50436 50437 .5000 1/2" 12.700 1/2" 4" 1-5/8" - - -
50438 50439 .5000 1/2" 12.700 1/2" 4" 1-5/8" .010" - -
50440 50441 .5000 1/2" 12.700 1/2" 4" 1-5/8" .020" - -
50442 50443 .5000 1/2" 12.700 1/2" 4" 1-5/8" .030" - -
50444 50445 .5000 1/2" 12.700 1/2" 4" 1-5/8" .040" - -
50446 50447 .5000 1/2" 12.700 1/2" 4" 1-5/8" .060" - -
50067 50321 .5000 1/2" 12.700 1/2" 4" 2-1/8" - - -
51033 - .5000 1/2" 12.700 1/2" 4" 2-1/8" .015" - -
50068 50322 .5000 1/2" 12.700 1/2" 4" 2-1/8" .030" - -
51034 - .5000 1/2" 12.700 1/2" 6" 1" .030" - -
51035 - .5000 1/2" 12.700 1/2" 6" 3-1/8" - - -
51036 - .5000 1/2" 12.700 1/2" 6" 3-1/8" .030" - -
51037 - .5000 1/2" 12.700 1/2" 4" 5/8" .015" 1-1/2" .475"
35 51038 - .5000 1/2" 12.700 1/2" 4" 5/8" .015" 2-1/4" .475"
6
50066 50320 .5000 1/2" 12.700 1/2" 4" 1-1/4" .030" 2-1/4" .475"
51039 - .5000 1/2" 12.700 1/2" 6" 5/8" .015" 3-3/8" .475"
51040 - .5000 1/2" 12.700 1/2" 6" 5/8" .015" 4-1/8" .475"
