GARR TOOL High Performance Milling Guide for V5, V5C
(High Efficiency Milling)
NOTE - DATA DOES NOT REFLECT CHIP THINNING. SEE GARR TOOL'S NEW CALCULATOR ON OUR WEBSITE. TECHNICAL
SPINDLE INTERFACE MUST BE SCRUTINIZED WHEN USING 16mm DIAMETER AND LARGER END MILLS
AD PER
T
OO
O
CHIPL
TH (Fz)
M/Min. CHIPLOAD PER TOOTH (Fz)
ISO Material HRC
(Vc) 6,0mm 8,0mm 10,0mm 12,0mm 16,0mm 20,0mm 25,0mm
/ Kobaltleg
lliages de c
o /
obalt
obalt
leaciones del c
o / A
ierungen / A
obalt / L
eghe del c
钴基合金
COBALT BASE ALLOYS / Kobaltlegierungen / Aleaciones del cobalto / Alliages de cobalt / Leghe del cobalto / 钴基合金
Haynes 25/188, Stellite 21, < 40 30 - 70 0,023 - 0,041 0,025 - 0,048 0,030 - 0,058 0,046 - 0,081 0,051 - 0,097 0,061 - 0,117 0,091 - 0,163
Cobalt Chrome > 40 27 - 55 0,018 - 0,036 0,020 - 0,043 0,025 - 0,053 0,036 - 0,071 0,041 - 0,086 0,051 - 0,107 0,071 - 0,142
lliage de nickel / L
leaciones de níquel / A
ickelleg
/ N
eghe di nichel /
ierungen / A
NICKEL BASE ALLOYS / Nickellegierungen / Aleaciones de níquel / Alliage de nickel / Leghe di nichel / 高镍基合金
高镍基合金
Inconel-625/718, Waspaloy, Invar, < 40 30 - 70 0,023 - 0,041 0,025 - 0,048 0,030 - 0,058 0,046 - 0,081 0,051 - 0,097 0,061 - 0,117 0,091 - 0,163
Rene, Hastelloy, Monel > 40 27 - 55 0,018 - 0,036 0,020 - 0,043 0,025 - 0,053 0,036 - 0,071 0,041 - 0,086 0,051 - 0,107 0,071 - 0,142
S IRON BASE ALLOYS / Eisenlegierungen / Aleaciones ferrosas / Alliages ferreux / Leghe ferrose / 铁基合金
ierungen / A
leaciones f
eghe f
eux / L
er
ose /
r
r
r
er
osas / A
er
lliages f
/ Eisenleg
铁基合金
A286, Discaloy, Haynes 556, < 40 30 - 70 0,023 - 0,041 0,025 - 0,048 0,030 - 0,058 0,046 - 0,081 0,051 - 0,097 0,061 - 0,117 0,091 - 0,163
Carpenter 22, Greek Ascolloy > 40 27 - 55 0,018 - 0,036 0,020 - 0,043 0,025 - 0,053 0,036 - 0,071 0,041 - 0,086 0,051 - 0,107 0,071 - 0,142
eghe di
itanleg
itane / L
ierungen / A
lliage de
leaciones de
itanio / A
T
T
/
T
T
itanio /
TITANIUM ALLOYS / Titanlegierungen / Aleaciones de Titanio / Alliage de Titane / Leghe di Titanio / 钛合金
钛合金
Commercially Pure, 6Al-4V,
Astm 1/2/3, 6Al-25N-4Zr-2Mo-Si 75 - 135 0,025 - 0,046 0,028 - 0,053 0,033 - 0,064 0,051 - 0,091 0,056 - 0,107 0,066 - 0,127 0,102 - 0,183
5553 / Beta Titanium 55 - 105 0,025 - 0,041 0,028 - 0,048 0,033 - 0,058 0,051 - 0,081 0,056 - 0,097 0,066 - 0,117 0,102 - 0,163
y
cier I
dable / A
x /
no
no
x
no
tähle / A
xidable / A
eie S
er
ostfr
/ R
ciaio I
c
c
o I
STAINLESS STEELS / Rostfreie Stähle / Acero Inoxidable / Acier Inoxydable / Acciaio Inox / 不锈钢合金
不锈钢合金
< 40 90 - 135 0,023 - 0,041 0,025 - 0,048 0,030 - 0,058 0,046 - 0,081 0,051 - 0,097 0,061 - 0,117 0,091 - 0,163
13/8, 15/5, 17-4, pH Types > 40 65 - 100 0,018 - 0,036 0,020 - 0,043 0,025 - 0,053 0,036 - 0,071 0,041 - 0,086 0,051 - 0,107 0,071 - 0,142
M 300 Series, 304L, Nitronic 50, < 40 90 - 145 0,023 - 0,041 0,025 - 0,048 0,030 - 0,058 0,046 - 0,081 0,051 - 0,097 0,061 - 0,117 0,091 - 0,163
Duplex, Super-Austenitic > 40 65 - 100 0,018 - 0,036 0,020 - 0,043 0,025 - 0,053 0,036 - 0,071 0,041 - 0,086 0,051 - 0,107 0,071 - 0,142
< 40 85 - 155 0,023 - 0,043 0,025 - 0,051 0,030 - 0,061 0,046 - 0,086 0,051 - 0,102 0,061 - 0,122 0,091 - 0,173
400 Series - 403, 405, 420, 455
> 40 65 - 120 0,018 - 0,038 0,020 - 0,046 0,025 - 0,056 0,036 - 0,076 0,041 - 0,091 0,051 - 0,112 0,071 - 0,152
e / A
amien
ciaio da ut
ta ac
r
ésistanc
eza / A
est
ciers à outils a haut
o /
c
e r
er
/ Hochf
os de alt
ensili molt
er
eugstähle / Her
kz
o dur
o dur
e
W
高强度工具钢
HIGH STRENGTH TOOL STEELS / Hochfeste Werkzeugstähle / Herramienta aceros de alto dureza / Aciers à outils a haute résistance / Acciaio da utensili molto duro / 高强度工具钢
A2, D2, P20, H13, S7, O1 < 40 85 - 145 0,023 - 0,043 0,025 - 0,051 0,030 - 0,061 0,046 - 0,086 0,051 - 0,102 0,061 - 0,122 0,091 - 0,173
0,071 - 0,142
0,018 - 0,036
0,041 - 0,086
> 40
55 - 120
0,025 - 0,053
0,036 - 0,071
0,020 - 0,043
0,051 - 0,107
c
ciaio da ut
ta medios de la aleación / A
t
ezza /
e
W
dur
ier
itt
/ M
el L
eg
ciers à outils alliés / A
er
c
os her
amien
r
kz
er
ensili di media
eugstähle / A
中碳
合金钢
P MEDIUM ALLOY TOOL STEELS / Mittel Legierte Werkzeugstähle / Aceros herramienta medios de la aleación / Aciers à outils alliés / Acciaio da utensili di media durezza / 中碳合金钢
0,046 - 0,091
0,023 - 0,046
0,030 - 0,064
0,025 - 0,053
0,061 - 0,127
< 40
0,051 - 0,107
0,091 - 0,183
130 - 180
4140, 4340, 52100, 6150, 8620 > 40 90 - 135 0,018 - 0,038 0,020 - 0,046 0,025 - 0,056 0,036 - 0,076 0,041 - 0,091 0,051 - 0,112 0,071 - 0,152
c
c
er
off
stahl / A
ciaio al car
bonio /
bón / A
cier du car
o de car
bone / A
/ Kohlenst
碳钢
CARBON STEELS / Kohlenstoffstahl / Acero de carbón / Acier du carbone / Acciaio al carbonio / 碳钢
1000’s - 1018, 1020, 12L14 < 40 135 - 220 0,028 - 0,048 0,030 - 0,056 0,036 - 0,066 0,056 - 0,097 0,061 - 0,112 0,071 - 0,132 0,112 - 0,193
er
egossenes M
ial bastidor v
a
/ G
tidos / M
er
er
t
a
t
a
ial / M
er
t
iaux f
on
a
es / M
t
t
iale fuso /
er
CAST MATERIAL / Gegossenes Material / Material bastidor vertidos / Materiaux fontes / Materiale fuso / 铸造件
铸造件
K Ductile Iron 130 - 190 0,028 - 0,048 0,030 - 0,056 0,036 - 0,066 0,056 - 0,097 0,061 - 0,112 0,071 - 0,132 0,112 - 0,193
Gray Iron 170 - 215 0,030 - 0,053 0,033 - 0,061 0,038 - 0,071 0,061 - 0,107 0,066 - 0,122 0,076 - 0,142 0,122 - 0,213
Profile/Trochoidal ap
Milling
Axial (ap) up to 2xD ae
Radial (ae) 5% - 15% of Dia.
NOTE - ABOVE ARE STARTING PARAMETERS ONLY. HIGHER RESULTS MAY BE ACHIEVED WITH OPTIMUM CONDITIONS.
