Fresa para roscar con plaquitas reversibles para taladrados profundos

Aplicación: ■ Para roscas grandes y profundas. L tot
■ Para rosca interior cilíndrica; otras plaquitas reversibles y soportes a petición.
■ Para roscas de agujero pasante y de agujero ciego.
■ De aplicación universal para rosca a la izquierda y a la derecha.
■ Presión de corte baja. ⌀activo D 1
D
21 8110

L 2 L 1
⌀ D 21R 21 8110 Tamaño de placa Número de filos Z Rosca de aloja- ⌀ activo D ⌀ D 1 L tot L 1 L 2 Tornillo para plaquita
Cabezal de fresado de miento
rosca
mm Mango Weldon mm mm mm mm mm
15 252,22 11 1 M6 14,75 10,6 20,2 15 5,2 279810 4 (TX8; 1,02 Nm)
17 258,12 11 1 M8 16,75 13 22,2 17 5,2 279810 4 (TX8; 1,02 Nm)
21 297,95 11 2 M8 20,75 14,1 19,2 14 5,2 279810 4 (TX8; 1,02 Nm)
23 296,47 11 2 M10 23,3 18 19,2 14 5,2 279810 4 (TX8; 1,02 Nm)
26 337,77 11 3 M12 26,5 21 25,2 20 5,2 279810 4 (TX8; 1,02 Nm)
31 458,72 11 4 M12 30,9 25 28 22,8 5,2 279810 4 (TX8; 1,02 Nm)
36 443,97 16 3 M16 35,5 29 32,95 25 7,95 279810 2 (TX10; 1,58 Nm)
42 510,35 16 4 M16 41 32 32,95 25 7,95 279810 5(TX10; 1,7 Nm)

Vista genera de los cabezales para fresar y las plaquitas

Seleccione el cabezal para fresar y la plaquita adecuada en función del intervalo de aplicación de roscas.

Rosca interior y exterior de 55°
Rosca interior 60° 21 8122 / 21 8124 21 8131 / 21 8133
Soportes D
Rosca normal ISO Rosca fina ISO UNC UN/UNF/UNEF/UNS BSP(G) Perfil parcial 55°
21 5/8–32UN; 5/8–28UN; 3/8–19;
21 8110_15 14,75 M18×2,5; M24×3,0 M16×0,5; M16×0,75; M16×1,0; 3/4–10 5/8–27UNS; 11/16–24UN; 1/2–14; 11/16–14; 3/4–12; 7/8–11;
M17×1,25; M17×1,5; M17×2,0 11/16–20UN; 11/16–16UN; 1–11 3/4–10; 7/8–9; 1–8; 1 1/8–7
3/4–14UNS; 3/4–12UN
3/4–32UN; 3/4–28UN;
M18×0,5; M18×0,75; M18×1,0; 7/8–27UN; 3/4–24UN; 34–20UN; 1/2–14; 13/16–12; 7/8–11; 1–10;
21 8110_17 16,75 M20×2,5; M24×3,0 M19×1,25; M19×1,5; M19×2,0 – 3/4–16UNF; 3/4–14UNS; 1–11 7/8–9; 1–8; 1 1/8–7
13/16–12UN; 7/8–10UN
7/8–32UN; 7/8–28UN;
1–8; 7/8–27UNS; 7/8–24UNS; 1–26; 1–20; 1–16;
M22×0,5; M22×0,75; M22×1,0; 3/4–14;
21 8110_21 20,75 M24×2,5; M30×3,5 1 1/8–7; 7/8–20UNEF; 1–18UNS; 1–12; 1–10; 1 1/8–9; 1–8;
M23×1,5; M23×2,0 1–11
1 3/8–6 15/16–16UN; 1–14UNS; 1 1/8–7
15/16–12UN; 1 –10UNS
1–32UN; 1–28UN; 1–27UNS;
M24×0,5; M24×0,75; M25×1,0; 1–26; 1–20; 1–16;
21 8110_23 23,3 M27×3,0; M30×3,5; M36×4,0 M25×1,25; M26×1,5; M26×2,0; 1 1/8–7 1–24UNS; 1–20UNEF; 1–18UNS; 3/4–14; 1 1/16–12; 1 1/8–9;
M27×2,5 1–16UN; 1–14UNS; 1–12UNF; 1–11 1 1/8–7
1 1/8–10UNS; 1 1/8-8UN
1 1/8–28UN; 1 1/8–24UNS;
M28×0,5; M28×0,75; M28×1,0;
21 8110_26 26,5 M33×2,5; M36×4,0 M28×1,25; M29×1,5; M29×2,0; 1 1/4–7; 1 1/8–18UNEF; 1 1/8–16UN; 7/8–14; 1 1/8–26; 1 1/8–20; 1 3/8–16;
1 1/4–14UNS; 1 3/16–12UN;
1 3/8–12; 1 3/8–8; 1 1/4–7
1 3/8–6
1–11
M30×2,5; M30×3,0
1 1/4–10UNS; 1 3/16–8UN
1 5/16–28UN; 1 3/8–24UNS;
M32×0,5; M32×0,75; M33×1,0; 1 5/16–20UN; 1 5/16–18UNEF;
21 8110_31 30,9 M36×4,0 M33×1,25; M33×1,5; M34×2,0; 1 1/2–6 1 5/16–16UN; 1 3/8–14UNS; 11/8–11 1 3/8–26; 1 3/8–20; 1 3/8–16;
1 3/8–12; 1–10; 1 7/16–8
M34×2,5; M35×3,0; M36×3,5 1 3/8–12UNF; 1 3/8–10UNS;
1 3/8–8UN
1 3/4–5; 1 9/16–16UN; 1 5/8–14UNS;
21 8110_36 35,5 M42×4,5; M48×5,0; M39×1,5; M39×2,0; M40×2,5; 2–4,5; 1 9/16–12UN; 1 5/8–10UNS; 1 1/4–11 1 5/8–16; 1 5/8–12; 1 5/8–8;
M56×5,5; M64×6,0 M41×3,0; M42×3,5; M42×4,0 1 7/8–6; 1 3/4–5
2 1/4–4 1 5/8–8UN; 1 5/8–6UN
1 3/4–16UN; 1 3/4–14UNS;
M45×1,5; M45×2,0; M46×2,5; 2–4,5; 1 7/8–16; 1 7/8–12; 1 7/8–8;
21 8110_42 41,0 M48×5,0; M56×5,5; M64×6,0 M48×3,5; M48×4,0 2 1/2–4 1 13/16–12UN; 1 13/16–8UN; 1 1/2–11 2 1/4–6; 2–4,5
1 51/16–6UN
