NIHS / NIHS NT
S DC SWISS NI584 / STB U758-002D-F

DZ04 GO DZ14 NOªGO DZ04 GO DZ14 NOªGO

l
2

d 1

l P
1

NIHS NIHS
NT NT

Ø d 1 P l 1 l GO d 2 ID ID ID ID
2
S mm mm mm
0.5 0.125 6 0.75 20 l 190812 l 190831 l 190850 l 190869
0.6 0.15 6 0.9 20 l 190813 l 190832 l 190851 l 190870
0.7 0.175 6 1.05 20 l 190814 l 190833 l 190852 l 190871
0.8 0.2 6 1.2 20 l 190815 l 190834 l 190853 l 190872
0.9 0.225 6 1.35 20 l 190816 l 190835 l 190854 l 190873
1 0.25 6 1.5 20 l 190817 l 190836 l 190855 l 190874
1.2 0.25 6 1.8 20 l 190818 l 190837 l 190856 l 190875
1.4 0.3 6 2.1 20 l 190819 l 190838 l 190857 l 190876

All nano ring gauges have a certificate of measurement, established with SCS certified plug check gauges.
The paid certificate is available on request.
