NIHS / NIHS NT
S DC SWISS NI584 / STB U758-002D-F

DN04 GO DN14 NOªGO DN04 GO DN14 NOªGO

l
2
d 2

d 1

l
1

P

NIHS NIHS
NT NT

Ø d 1 P l 1 l GO d 2 ID ID ID ID
2
S mm mm mm
0.5 0.125 24 0.75 6 l 190888 l 190907 l 190926 l 190945
0.6 0.15 24 0.9 6 l 190889 l 190908 l 190927 l 190946
0.7 0.175 24 1.05 6 l 190890 l 190909 l 190928 l 190947
0.8 0.2 24 1.2 6 l 190891 l 190910 l 190929 l 190948
0.9 0.225 24 1.35 6 l 190892 l 190911 l 190930 l 190949
1 0.25 24 1.5 6 l 190893 l 190912 l 190931 l 190950
1.2 0.25 24 1.8 6 l 190894 l 190913 l 190932 l 190951
1.4 0.3 24 2.1 6 l 190895 l 190914 l 190933 l 190952

All nano ring gauges have a certificate of measurement, established with SCS certified plug check gauges.
