Page 201 - DC_SWISS(Catalogue_TM_ES-EN)

~ ISO 529
HSS
UNEF ASME B1.1 ~ ISO 529

N1110 3 N1120 4 N1210 3 N1220 4

N

N1110-3 31 62 73 74 91

62 63 72 73 74
N1120-4
81 91

N1210-3 31 62 73 74 91

< 1.5 x D < 1.5 x D
62 63 72 73 74
N1220-4
81 91

C B C B
a
d 2
2 x P 4 x P 2 x P 4 x P
d 1
l
2
l
3 l P
1
Ø’’ d 1 P d 1 l 1 l 2 l 3 d 2 a ID ID ID ID
UNEF TPI mm mm mm mm mm mm
12 32 5.48 62 17 26 5.6 4.5 3 4.7 l 103007 l 103118
1/4 32 6.35 66 19 30 6.3 5 3 5.6 l 103006 l 103117
5/16 32 7.93 72 22 35 8 6.3 3 7.2 l 103009 l 103120
3/8 32 9.52 80 24 39 10 8 3 8.75 l 103008 l 103119
7/16 28 11.11 85 22 8 6.3 3 10.25 l 103615 l 103754
1/2 28 12.7 89 24 9 7.1 3 11.85 l 103609 l 103749
9/16 24 14.28 95 24 11.2 9 3 13.2 l 103617 l 103756
5/8 24 15.87 102 32 12.5 10 3 14.8 l 103614 l 103753
11/16 24 17.46 104 26 14 11.2 4 16.4 l 103611
3/4 20 19.05 112 33 14 11.2 4 17.8 l 103613
7/8 20 22.22 115 32 16 12.5 4 21 l 103616
1 20 25.4 120 30 18 14 4 24.1 l 103610
