DIXI 1137-8D

BROCAS HELICOIDALES P.78 P.73 D ≥ 0.5
MANGO REFORZADO 1

D 1 0/-0.004 L 1 D h5 L CARBURO C-TOP DRYCUT* D 1 0/-0.004 L 1 D h5 L CARBURO C-TOP DRYCUT*

1.61 12.9 2.0 38 423006 423166 423326 2.60 20.8 3.0 50 416113 416581 416289
1.62 13.0 2.0 38 423007 423167 423327 2.70 21.6 3.0 50 416114 416582 416290
1.63 13.1 2.0 38 423008 423168 423328 2.80 22.4 3.0 50 416115 416583 416291
1.64 13.2 2.0 38 423009 423169 423329 2.90 23.2 3.0 50 416116 416584 416292
1.65 13.2 2.0 38 416100 416568 416276 3.00 24.0 3.0 50 416117 416585 416293
1.66 13.3 2.0 38 423010 423170 423330 3.10 25.0 4.0 75 416118 416586 416294
1.67 13.4 2.0 38 423011 423171 423331 3.20 26.0 4.0 75 416119 416587 416295
1.68 13.5 2.0 38 423012 423172 423332 3.30 27.0 4.0 75 416120 416588 416296
1.69 13.6 2.0 38 423013 423173 423333 3.40 28.0 4.0 75 416121 416589 416297
1.70 13.6 2.0 38 416101 416569 416277 3.50 28.0 4.0 75 416122 416590 416298
1.71 13.7 2.0 38 423014 423174 423334 3.60 29.0 4.0 75 416123 416591 416299
1.72 13.8 2.0 38 423015 423175 423335 3.70 30.0 4.0 75 416124 416592 416300
1.73 13.9 2.0 38 423016 423176 423336 3.80 31.0 4.0 75 416125 416593 416301
1.74 14.0 2.0 38 423017 423177 423337 3.90 32.0 4.0 75 416126 416594 416302
1.75 14.0 2.0 38 416102 416570 416278
4.00 32.0 4.0 75 416127 416595 416303
1.76 14.1 2.0 38 423018 423178 423338
4.10 33.0 6.0 100 416128 416596 416304
1.77 14.2 2.0 38 423019 423179 423339
4.20 34.0 6.0 100 416129 416597 416305
1.78 14.3 2.0 38 423020 423180 423340
4.30 35.0 6.0 100 416130 416598 416306
1.79 14.4 2.0 38 423021 423181 423341
4.40 36.0 6.0 100 416131 416599 416307
1.80 14.4 2.0 38 416103 416571 416279
4.50 36.0 6.0 100 416132 416600 416308
1.81 14.5 2.0 38 423022 423182 423342
4.60 37.0 6.0 100 416133 416601 416309
1.82 14.6 2.0 38 423023 423183 423343
4.70 38.0 6.0 100 416134 416602 416310
1.83 14.7 2.0 38 423024 423184 423344
4.80 39.0 6.0 100 416135 416603 416311
1.84 14.8 2.0 38 423025 423185 423345
4.90 40.0 6.0 100 416136 416604 416312
1.85 14.8 2.0 38 416104 416572 416280
5.00 40.0 6.0 100 416137 416605 416313
1.86 14.9 2.0 38 423026 423186 423346
5.10 41.0 6.0 100 416138 416606 416314
1.87 15.0 2.0 38 423027 423187 423347
1.88 15.1 2.0 38 423028 423188 423348 5.20 42.0 6.0 100 416139 416607 416315
5.30 43.0 6.0 100 416140 416608 416316
1.89 15.2 2.0 38 423029 423189 423349
5.40 44.0 6.0 100 416141 416609 416317
1.90 15.2 2.0 38 416105 416573 416281
1.91 15.3 2.0 38 423030 423190 423350 5.50 44.0 6.0 100 416142 416610 416318
1.92 15.4 2.0 38 423031 423191 423351 5.60 45.0 6.0 100 416143 416611 416319
1.93 15.5 2.0 38 423032 423192 423352 5.70 46.0 6.0 100 416144 416612 416320
1.94 15.6 2.0 38 423033 423193 423353 5.80 47.0 6.0 100 416145 416613 416321
1.95 15.6 2.0 38 416106 416574 416282 5.90 48.0 6.0 100 416146 416614 416322
1.96 15.7 2.0 38 423034 423194 423354 6.00 48.0 6.0 100 416147 416615 416323
1.97 15.8 2.0 38 423035 423195 423355 *para materiales no ferrosos
1.98 15.9 2.0 38 423036 423196 423356
1.99 16.0 2.0 38 423037 423197 423357
2.00 16.0 3.0 50 416107 416575 416283
2.10 16.8 3.0 50 416108 416576 416284
2.20 17.6 3.0 50 416109 416577 416285
2.30 18.4 3.0 50 416110 416578 416286
2.40 19.2 3.0 50 416111 416579 416287
2.50 20.0 3.0 50 416112 416580 416288
