P. 38
DIXI 1137-5D
BROCAS HELICOIDALES P.78 P.73 D ≥ 0.5
MANGO REFORZADO 1
D 1 0/-0.004 L 1 D h5 L CARBURO C-TOP DRYCUT* D 1 0/-0.004 L 1 D h5 L CARBURO C-TOP DRYCUT*
1.62 8.10 2 32 422927 423087 423247 2.70 13.50 3 38 377842 416436 378347
1.63 8.20 2 32 422928 423088 423248 2.80 14.00 3 38 377843 416437 378348
1.64 8.20 2 32 422929 423089 423249 2.90 14.50 3 38 377844 416438 378349
1.65 8.30 2 32 377828 416422 378333 3.00 15.00 3 38 377845 416439 378350
1.66 8.30 2 32 422930 423090 423250 3.10 16.00 4 60 415972 416440 416148
1.67 8.40 2 32 422931 423091 423251 3.20 16.00 4 60 415973 416441 416149
1.68 8.40 2 32 422932 423092 423252 3.30 17.00 4 60 415974 416442 416150
1.69 8.50 2 32 422933 423093 423253 3.40 17.00 4 60 415975 416443 416151
1.70 8.50 2 32 377829 416423 378334 3.50 18.00 4 60 415976 416444 416152
1.71 8.60 2 32 422934 423094 423254 3.60 18.00 4 60 415977 416445 416153
1.72 8.60 2 32 422935 423095 423255 3.70 19.00 4 60 415978 416446 416154
1.73 8.70 2 32 422936 423096 423256 3.80 19.00 4 60 415979 416447 416155
1.74 8.70 2 32 422937 423097 423257 3.90 20.00 4 60 415980 416448 416156
1.75 8.80 2 32 377830 416424 378335 4.00 20.00 4 60 415981 416449 416157
1.76 8.80 2 32 422938 423098 423258 4.10 21.00 6 75 415982 416450 416158
1.77 8.90 2 32 422939 423099 423259 4.20 21.00 6 75 415983 416451 416159
1.78 8.90 2 32 422940 423100 423260 4.30 22.00 6 75 415984 416452 416160
1.79 9.00 2 32 422941 423101 423261 4.40 22.00 6 75 415985 416453 416161
1.80 9.00 2 32 377831 416425 378336 4.50 23.00 6 75 415986 416454 416162
1.81 9.10 2 32 422942 423102 423262 4.60 23.00 6 75 415987 416455 416163
1.82 9.10 2 32 422943 423103 423263 4.70 24.00 6 75 415988 416456 416164
1.83 9.20 2 32 422944 423104 423264 4.80 24.00 6 75 415989 416457 416165
1.84 9.20 2 32 422945 423105 423265 4.90 25.00 6 75 415990 416458 416166
1.85 9.30 2 32 377832 416426 378337 5.00 25.00 6 75 415991 416459 416167
1.86 9.30 2 32 422946 423106 423266 5.10 26.00 6 75 415992 416460 416168
1.87 9.40 2 32 422947 423107 423267 5.20 26.00 6 75 415993 416461 416169
1.88 9.40 2 32 422948 423108 423268 5.30 27.00 6 75 415994 416462 416170
1.89 9.50 2 32 422949 423109 423269 5.40 27.00 6 75 415995 416463 416171
1.90 9.50 2 32 377833 416427 378338 5.50 28.00 6 75 415996 416464 416172
1.91 9.60 2 32 422950 423110 423270 5.60 28.00 6 75 415997 416465 416173
1.92 9.60 2 32 422951 423111 423271 5.70 29.00 6 75 415998 416466 416174
1.93 9.70 2 32 422952 423112 423272 5.80 29.00 6 75 415999 416467 416175
1.94 9.70 2 32 422953 423113 423273 5.90 30.00 6 75 416000 416468 416176
1.95 9.80 2 32 377834 416428 378339 6.00 30.00 6 75 416001 416469 416177
1.96 9.80 2 32 422954 423114 423274
*para materiales no ferrosos
1.97 9.90 2 32 422955 423115 423275
1.98 9.90 2 32 422956 423116 423276
1.99 10.00 2 32 422957 423117 423277
2.00 10.00 3 38 377835 416429 378340
2.10 10.50 3 38 377836 416430 378341
2.20 11.00 3 38 377837 416431 378342
2.30 11.50 3 38 377838 416432 378343
2.40 12.00 3 38 377839 416433 378344
2.50 12.50 3 38 377840 416434 378345
2.60 13.00 3 38 377841 416435 378346
36
