P. 19
POLY 4005-TC
SOLID CARBIDE REAMERS, RIGHT-HAND HELIX
ESCARIADORES DE CARBURO MONOBLOC, HÉLICE A DERECHA
整体硬质合金铰刀，右手切削 P. 64 > Ø 2.97
FROM STOCK
EN STOCK
库存
D nom. D L D L Z HM D nom. D L D L Z HM
h5
1
1
1
1
h5
H7 ± 1.5 m H7 ± 1.5 m
2.97 (2.977) 20 2.5 56 4 969074 3.75 (3.758) 20 3.0 56 4 969430
2.99 (2.997) 20 2.5 56 4 969379 3.78 (3.788) 20 3.0 56 4 969431
3.00 (3.007) 20 2.5 56 4 969382 3.80 (3.808) 20 3.0 56 4 969432
3.01 (3.018) 20 2.5 56 4 969398 3.85 (3.858) 20 3.0 56 4 969433
3.02 (3.028) 20 2.5 56 4 969399 3.90 (3.908) 20 3.0 56 4 969434
3.05 (3.058) 20 2.5 56 4 969400 3.95 (3.958) 20 3.0 56 4 969435
3.08 (3.088) 20 2.5 56 4 969401 4.00 (4.008) 20 3.0 56 4 969436
3.10 (3.108) 20 2.5 56 4 969402 4.04 (4.048) 22 3.5 63 6 993718
3.11 (3.118) 20 2.5 56 4 969403 4.10 (4.108) 22 3.5 63 6 969437
3.15 (3.158) 20 2.5 56 4 969404 4.20 (4.208) 22 3.5 63 6 969438
3.18 (3.188) 20 2.5 56 4 969405 4.30 (4.308) 22 3.5 63 6 969439
3.20 (3.208) 20 2.5 56 4 969406 4.40 (4.408) 22 3.5 63 6 969440
3.21 (3.218) 20 2.5 56 4 969407 4.50 (4.508) 22 4.0 63 6 969441
3.25 (3.258) 20 2.5 56 4 969408 4.60 (4.608) 22 4.0 63 6 969442
3.28 (3.288) 20 2.5 56 4 969409 4.70 (4.708) 22 4.0 63 6 969443
3.30 (3.308) 20 2.5 56 4 969410 4.80 (4.808) 22 4.0 63 6 969444
3.31 (3.318) 20 2.5 56 4 969411 4.90 (4.908) 22 4.0 63 6 969445
3.35 (3.358) 20 2.5 56 4 969412 5.00 (5.008) 22 4.0 63 6 969446
3.38 (3.388) 20 2.5 56 4 969413 5.10 (5.108) 22 4.0 63 6 969447
3.40 (3.408) 20 2.5 56 4 969414 5.20 (5.208) 22 4.0 63 6 969448
3.41 (3.418) 20 2.5 56 4 969415 5.30 (5.308) 22 4.0 63 6 969449
3.45 (3.458) 20 2.5 56 4 969416 5.40 (5.408) 22 4.0 63 6 969450
3.49 (3.498) 20 2.5 56 4 969417 5.50 (5.508) 22 5.0 63 6 969451
3.50 (3.508) 20 3.0 56 4 969418 5.60 (5.608) 22 5.0 63 6 969452
3.51 (3.518) 20 3.0 56 4 969421 5.70 (5.708) 22 5.0 63 6 969453
3.55 (3.558) 20 3.0 56 4 969422 5.80 (5.808) 22 5.0 63 6 969454
3.58 (3.588) 20 3.0 56 4 969423 5.90 (5.908) 22 5.0 63 6 969455
3.60 (3.608) 20 3.0 56 4 969424 6.00 (6.008) 22 5.0 63 6 969456
3.61 (3.618) 20 3.0 56 4 969425 6.10 (6.110) 22 5.0 63 6 969457
3.65 (3.658) 20 3.0 56 4 969426 6.20 (6.210) 22 5.0 63 6 969458
3.68 (3.688) 20 3.0 56 4 969427 6.30 (6.310) 22 5.0 63 6 969459
3.70 (3.708) 20 3.0 56 4 969428 6.40 (6.410) 22 5.0 63 6 969460
3.71 (3.718) 20 3.0 56 4 969429 6.50 (6.510) 22 5.0 63 6 969461
All Ø with tolerance ±2 m available through our express-service
Cualquier diámetro disponible sobre demanda con tolerancia ±2 m
a través de nuestro servicio rápido
通过我们特殊定制，所有直径尺寸公差可达±2 μm
P. 73
