P. 213
Cylindrical end mills
I
Profiled NRF, normal version, Pericool
h ƍ
a ƍ
Roughing Finishing
GG(G)
Rm Rm Rm Inox Ti
< 850 850-1100 1100-1300 Stainless Titanium
UNICUT-4X
Coating Article-N°. ø-Code
Example: U0695
Order-N°. U 0695 402
Ø d 1 d 2 α
Code k12 h6 l 1 l 2 l 4 45° z
402 8.00 10.00 69 19.00 69.00 0.30 1.0° 4 •
450 10.00 10.00 72 22.00 - 0.30 0.0° 4 •
501 12.00 12.00 83 26.00 - 0.30 0.0° 4 •
610 16.00 16.00 92 32.00 - 0.40 0.0° 4 •
682 20.00 20.00 104 38.00 - 0.40 0.0° 4 •
772 25.00 25.00 121 45.00 - 0.60 0.0° 6 •
832 32.00 32.00 133 53.00 - 0.60 0.0° 7 •
fraisa.com
211
