Page 792 - 21-036 APPLITEC catalogue.indb
P. 792
Inserts
10mm
NX SX HX ZX
Steel Stainless Steel Hardened Steel Difficult-to-cut materials
W52110010 W52310010 W52210010 W52410010
Inserts Delivery range: Packaging unit 10 pieces
Order-N°. ISO-Norm H B D r R theo.
W52110010 XDLT 10T308SR 10.2 10.0 4.0 0.800 2.00 •
W52310010 XDLT 10T308ER 10.2 10.0 4.0 0.800 2.00 •
W52210010 XDLW 10T308SR 10.2 10.0 4.0 0.800 2.00 •
W52410010 XDLT 10T308ER 10.2 10.0 4.0 0.800 2.00 •
FRAISA ToolExpert®
The online cutting data tool for optimum tool use.
This way to the cutting data calculator ToolExpert
fraisa.com
790
