Legend to the product page
Form of the corner of the cutting edges
The corner between the front side blade and the circumference blade has a protective chamfer of 45°.
The size of the protective chamfer is stated for each diameter in the data table on the catalog page.
The tool is furnished with a corner radius. For every diameter the size of the radius is listed in the
corresponding data table of the catalog.
The corner between front cutting edge and circumferential cutting edge is executed sharp-edged.
High Feed Cutting (HFC) tool. Tool with a special cutting geometry for high feed milling.
High Feed Cutting (HFC) tool with corner radius. Tool with special cutting edge geometry for high feed
machining.
