Page 217 - Carbide drills I Thread cutting tools 2023
P. 217
Taps x-tap-R
Incool
M
Inox
Stainless
TRIBO
Article-N°. ø-Code
Example: ET0591
Order-N°. ET0591 058
Ø d 2
Code d P L l l 1 l 3 h6
058 M 4 0.70 66 7.00 - 19.0 6.0 3 3.40 •
084 M 5 0.80 70 8.00 - 23.0 6.0 3 4.30 •
088 M 6 1.00 80 10.00 - 28.0 6.0 3 5.10 •
160 M 8 1.25 90 13.00 35.0 33.0 8.0 3 6.90 •
174 M 10 1.50 100 15.00 39.0 37.0 10.0 4 8.60 •
240 M 12 1.75 110 18.00 45.0 43.0 12.0 4 10.40 •
244 M 14 2.00 110 20.00 46.0 44.0 16.0 4 12.20 •
246 M 16 2.00 110 20.00 50.0 48.0 16.0 4 14.20 •
312 M 18 2.50 125 25.00 60.0 58.0 16.0 4 15.70 •
314 M 20 2.50 140 25.00 64.0 62.0 16.0 4 17.70 •
316 M 22 2.50 140 25.00 64.0 62.0 20.0 5 19.70 •
320 M 24 3.00 160 30.00 74.0 72.0 20.0 5 21.20 •
fraisa.com
215
