Page 216 - Carbide drills I Thread cutting tools 2023

n
v c
n
d
P
v c
v c
n
Application Material M [mm] [mm] 1.0 x d [min ] -1 1.5 x d [min ] -1 2.0 x d [min ] -1
Stainless steel M 4 4.000 0.70 12 955 10 795 8 635
ferritc/martensitic M 5 5.000 0.80 12 765 10 635 8 510
M 6 6.000 1.00 12 635 10 530 8 425
M 8 8.000 1.25 12 475 10 400 8 320
M 10 10.000 1.50 12 380 10 320 8 255
M 12 12.000 1.75 12 320 10 265 8 210
M 14 14.000 2.00 12 275 10 225 8 180
M 16 16.000 2.00 12 240 10 200 8 160
M 18 18.000 2.50 12 210 10 175 8 140
Stainless steel M 20 20.000 2.50 12 190 10 160 8 125
ferritc/martensitic M 22 22.000 2.50 12 175 10 145 8 115
M 24 24.000 3.00 12 160 10 135 8 105
Stainless steel M 4 4.000 0.70 7 555 5 400 4 320
[Cr-Ni/1.4301] M 5 5.000 0.80 7 445 5 320 4 255
M 6 6.000 1.00 7 370 5 265 4 210
M 8 8.000 1.25 7 280 5 200 4 160
M 10 10.000 1.50 7 225 5 160 4 125
M 12 12.000 1.75 7 185 5 135 4 105
M 14 14.000 2.00 7 160 5 115 4 90
M 16 16.000 2.00 7 140 5 100 4 80
M 18 18.000 2.50 7 125 5 90 4 70
Stainless steel M 20 20.000 2.50 7 110 5 80 4 65
[Cr-Ni/1.4301] M 22 22.000 2.50 7 100 5 70 4 60
M 24 24.000 3.00 7 95 5 65 4 55

Stainless steel M 4 4.000 0.70 8 635 6 475 5 400
[Cr-Ni-Mo-.../1.4571] M 5 5.000 0.80 8 510 6 380 5 320
M 6 6.000 1.00 8 425 6 320 5 265
M 8 8.000 1.25 8 320 6 240 5 200
M 10 10.000 1.50 8 255 6 190 5 160
M 12 12.000 1.75 8 210 6 160 5 135
M 14 14.000 2.00 8 180 6 135 5 115
M 16 16.000 2.00 8 160 6 120 5 100
M 18 18.000 2.50 8 140 6 105 5 90
Stainless steel M 20 20.000 2.50 8 125 6 95 5 80
[Cr-Ni-Mo-.../1.4571] M 22 22.000 2.50 8 115 6 85 5 70
M 24 24.000 3.00 8 105 6 80 5 65

Heat resistant steel M 4 4.000 0.70 5 400 4 320 - -
[17-4 PH] M 5 5.000 0.80 5 320 4 255 - -
M 6 6.000 1.00 5 265 4 210 - -
M 8 8.000 1.25 5 200 4 160 - -
M 10 10.000 1.50 5 160 4 125 - -
M 12 12.000 1.75 5 135 4 105 - -
M 14 14.000 2.00 5 115 4 90 - -
M 16 16.000 2.00 5 100 4 80 - -
M 18 18.000 2.50 5 90 4 70 - -
Heat resistant steel M 20 20.000 2.50 5 80 4 65 - -
[17-4 PH] M 22 22.000 2.50 5 70 4 60 - -
M 24 24.000 3.00 5 65 4 55 - -
