P. 223
Taps durotap GG-R
M
GG(G)
TiCN
Article-N°. ø-Code
Example: EH6500
Order-N°. EH6500 044
Ø d 2
Code d P L l l 1 l 3 h6
044 M 3 0.50 63 2.50 18.0 16.0 6.0 3 2.50 •
058 M 4 0.70 63 3.50 21.0 19.0 6.0 3 3.30 •
084 M 5 0.80 70 4.00 25.0 23.0 6.0 3 4.20 •
088 M 6 1.00 80 5.00 30.0 28.0 6.0 3 5.00 •
160 M 8 1.25 90 6.50 35.0 33.0 8.0 3 6.80 •
174 M 10 1.50 100 7.50 39.0 37.0 10.0 3 8.50 •
240 M 12 1.75 110 9.00 45.0 43.0 12.0 3 10.20 •
Ongoing coating changeover as of 01.04.23 from TiCN to AlCrTiN fraisa.com
221
