P. 125

USER GUIDE
                                                                                                                      INDEXABLE DRILLS












                     Cutting Speed  (1)                             Feed vs. Drill Diameter mm/rev
          Mat.   Vc m/min     Vc m/min
           No.   IC808/ 908   IC8080 /9080   DR-04   DR-05   DR-06      DR-07    DR-09/10   DR-11/12   DR-14/16
                  external    external  AL/DT/HD GF/DT/AL/HD GF/DT/AL/HD GF/DT/AL/HD GF/DT/AL/HD GF/DT/AL/HD GF/DT/AL/HD
            1
            2     200-300     260-390            0.06-0.10   0.07-0.12   0.08-0.12   0.10-0.15  0.12-0.16  0.14-0.17
                                                                       0.12-0.18
                                                 0.10-0.15
                                                                                  0.14-0.22
                                                            0.10-0.16
                                                                                            0.15-0.25
                                                                                                       0.16-0.26
            3                                    0.04-0.08  0.04-0.08  0.05-0.10  0.05-0.10  0.08-0.15  0.08-0.15
            4     150-200     190-260
            5
            6     150-220     190-290            0.06-0.10  0.07-0.12  0.08-0.12  0.10-0.14  0.12-0.15  0.14-0.16
            7                                    0.10-0.14   0.10-0.15   0.10-0.16   0.14-0.20   0.14-0.22   0.15-0.24
            8     120-180     160-230   0.04-0.08   0.04-0.08  0.04-0.08  0.05-0.10  0.05-0.10  0.08-0.15  0.08-0.15
            9                           0.02-0.06
           10     120-190     160-250            0.06-0.10  0.06-0.10  0.06-0.10   0.08-0.12  0.10-0.15   0.14-0.17
                                                 0.10-0.14  0.10-0.14  0.10-0.14  0.12-0.18  0.14-0.20  0.16-0.24
           11     100-160     210-310            0.08-0.112  0.08-0.112  0.08-0.112  0.096-0.144  0.112-0.160  0.128-0.192
           12                                    0.06-0.10  0.06-0.10  0.06-0.12  0.08-0.12  0.10-0.14  0.12-0.20
           13     160-240     210-310            0.048-0.08  0.048-0.08  0.048-0.096  0.064-0.096  0.08-0.112  0.096-0.160
           14     160-240     210-310   0.04-0.08  0.06-0.10  0.06-0.10  0.06-0.12  0.08-0.12  0.10-0.14  0.12-0.20
           15
           16     150-250     190-320
           17
           18     120-180     160-230   0.08-0.16  0.10-0.22  0.10-0.22  0.10-0.22  0.15-0.25  0.18-0.30  0.20-0.34
           19
           20
           21
           22
           23
           24
           25
           26     150-300     190-390   0.08-0.24  0.12-0.25  0.12-0.25  0.12-0.25  0.20-0.30  0.2-0.35  0.28-0.45
           27
           28
           29
           30
           31
           32
           33     20-50        30-60
           34                           0.03-0.07  0.04-0.08  0.04-0.08  0.05-0.09  0.07-0.10  0.08-0.12  0.10-0.14
           35
           36
           37     50-60        60-80
           38     20-50        30-60
           39
           40                           0.04-0.08  0.05-0.08  0.05-0.08  0.06-0.09  0.07-0.10  0.08-0.12  0.10-0.14
           41
          (1)   Central insert should always be IC808/IC908
          •  This table refers to 2/3xD drill lengths. For 4xD and 5XD drills, decrease cutting data by 15%
          •  When using only external coolant supply, reduce cutting speed by 10%
          •  Use internal coolant supply when machining austenitic stainless steel
