USER GUIDE
INDEXABLE DRILLS

Setup of Non-Rotating Drills

Machining Conditions Make sure the center line of the drill is aligned with the
spindle center line. It is recommended to verify the setup
Optimizing Chip Shape for DR Drills
according to the instructions shown below.
L DR-06
L1
h2

h1 D-0.3 (mm)

DT GF D+1 (mm)
Under regular conditions it is possible to adjust
the center line of the drill (X-axis of the machine)
in order to change hole diameter size.
General use
For ISO – P/M/K/H/S For low up to medium
materials feed rates
For medium up to For ISO – P material
high feed rates L – close
L – open H2 – high
H2 – low L1 – small CORE
L1 – medium H1 – deep
H1 – shallow
1 Drill a hole 6 mm deep with the drill center
AL HD line aligned with the spindle center line.
2 Check the existing core. If there is no core, check the
alignment of the Y-axis of the drill and spindle. Correct
by checking the adapter or adjusting the Y-axis.
3 Check that the hole diameter equals the drill diameter
+0.0- +0.2 mm. If not, adjust the X-axis.
4 Note: In some operations, part of the core may break.
For medium up to For low up to medium If this occurs, use finger contact to verify if any
high feed rates feed rates core remains
For ISO – N material For ISO – P material
L – open L – open
H2 – high H2 – high Warning: As the drill goes all the way through
L1 – non L1 – non a workpiece, it ejects a disc.
H1 – deep H1 – non For worker safety, guards should be used..

Drilling Insert Grades

Grades for Applications and Materials
Material Groups ISO P ISO M ISO K ISO N ISO S ISO H
1-11 12-13 14 15-20 21-28 31-37 38-41
Stainless
Steel Stainless Steel High Hard
Steel Austenitic & Duplex Cast Iron Nonferrous
Ferritic & Temp Steel
Main Applications Martensitic (Ferritic-Austenitic)
Harder

IC808 (908) IC808 (908) IC808 (908) IC8080 (9080) IC808 (908) IC808 (908) IC808 (908)
(1)
DRILLING IC5500 IC808 (908)
Tougher
(1) Use for an outer insert on DR drills
Default recommendation
