USER GUIDE




         Requested Information Form for Deep Hole Drill Design



            Company name                                        Telephone no.

            Address                                             Date
            Contact person                                      Customer no.

            Workpiece                                                                                                 DEEP DRILLING - BTA SYSTEM

            Product name:                                              Hole diameter:
            Hole depth:                    No. of holes:               Tolerance (of hole):

            Surface finish (Rz, Ra...):    Deviation (mm/100):         Straightness (mm/100):
            Material

            Material (DIN, AISI, JIS...):
            Hardness (HB, HS, HRC...):

            Condition:           o Quenched         o Tempered         o Cast       o Annealed
                                 o Other
            Machine

            Machine supplier name:

            Machine type/model:  o NC lathe         o Machining center  o Other
            Rigidity:            o Good             o Normal           o Poor

            Spindle power (kW):

            Tool and/or workpiece rotation (TR/WR):
            o Tool and workpiece     o Rotating workpiece (WR)         o Rotating tool (TR)

            Type of Coolant
            Water based:         o Soluble                             o Emulsion                        %

            Oil based:           o Coolant Pressure (bar):             Coolant Volume (L/min):
            Tool Drill Head

            Drill diameter:                          (mm/inch)
            Thread:              o Inner            o Outer            o Brazed

            Indexable:           o Adjustable       o Direct mount     Coating:      o Coated   o Uncoated
            o Solid drilling                                           o Counterboring

            Pre-drilled hole size:                   (mm/inch)

            Bottom finishing:    o Full ball R      o Flat bottom R    o Corner R    o Other
            Trepanning:          o Y       o N

            Tube outer diameter:                     (mm/inch)  Core size diameter:                (mm/inch)
            Please fill in and return to your ISCAR representative.
