      DEEP DRILLING - BTA SYSTEM



          Requested Information Form for Deep Hole Drill Design (continued)


             Tube

             Outside diameter:                          (mm/inch)  Total Length:                     (mm/inch)
             Internal Thread:

             External Thread:  4  o Starts           2 o Starts          1   o Starts

             Tube Thread:     1  o End                 o Both ends
             Inner Tube Length:                         (mm/inch)

             Inner Tube Slit:  1  o End                o Both ends

             Drilling System & Boring Conditions

             o Single Tube System:                     o Blind Hole Drilling  o Double Tube System

             o Cross Hole Drilling:                    o Through Hole Drilling
             Please Sketch Your Drilling Application
























             General Production Information

             Quantity of parts per year:

             Grade, tool life, etc.:

             Perfomance expectation:   Vc=   m/min   N=        RPM     F=         mm/min  f=          mm/rev

             Cutting data:

             Description of present system in use:













             Please fill in and return to your ISCAR representative.
