GUNDRILLS  GD-DHL                  DC -0.07  PL       LU       OAL  BD           LS      DCONMSh6

                                            0
          Gundrills Carrying Indexable
          Inserts with 2 Chip Splitting
          Cutting Edges and a Wiper for
          High Hole Surface Quality

                                                                                     PL
                                                      OAL
                                  DC
           Designation
                                            LU
                                                                           BD
                                                                                                LS
                                                                                                         Insert
           GD-DHL 12.00X800-U03
                                                                19.05
           GD-DHL 12.00X800-22
                                                                           11.50
                                            733.80
                                  12.00
                                                                20.00
                                                                                     1.80
                                                                                               50.0
                                                                                                        LOGT 06..
                                                      801.80
           GD-DHL 12.00X800-34    12.00     713.80    801.80   DCONMS      11.50     1.80      70.0     LOGT 06..
                                                      801.80
                                                                           11.50
                                  12.00
                                                                20.00
                                                                                                        LOGT 06..
                                                                                               50.0
                                                                                     1.80
                                            733.80
           GD-DHL 12.00X1000-U03  12.00     913.80    1001.80   19.05      11.50     1.80      70.0     LOGT 06..
           GD-DHL 12.00X1000-22   12.00     933.80    1001.80   20.00      11.50     1.80      50.0     LOGT 06..
           GD-DHL 12.00X1000-34   12.00     933.80    1001.80   20.00      11.50     1.80      50.0     LOGT 06..
           GD-DHL 12.00X1650-U03  12.00    1563.80    1651.80   19.05      11.50     1.80      70.0     LOGT 06..
           GD-DHL 12.00X1650-22   12.00    1583.80    1651.80   20.00      11.50     1.80      50.0     LOGT 06..
           GD-DHL 12.00X1650-34   12.00    1583.80    1651.80   20.00      11.50     1.80      50.0     LOGT 06..
           GD-DHL 13.00X800-U04   13.00     711.80    801.80    25.40      12.50     1.80      70.0     LOGT 06..
           GD-DHL 13.00X800-23    13.00     725.80    801.80    25.00      12.50     1.80      56.0     LOGT 06..
           GD-DHL 13.00X800-35    13.00     725.80    801.80    25.00      12.50     1.80      56.0     LOGT 06..
           GD-DHL 13.00X1000-U04  13.00     911.80    1001.80   25.40      12.50     1.80      70.0     LOGT 06..
           GD-DHL 13.00X1000-23   13.00     925.80    1001.80   25.00      12.50     1.80      56.0     LOGT 06..
           GD-DHL 13.00X1000-35   13.00     925.80    1001.80   25.00      12.50     1.80      56.0     LOGT 06..
           GD-DHL 13.00X1650-U04  13.00    1561.80    1651.80   25.40      12.50     1.80      70.0     LOGT 06..
           GD-DHL 13.00X1650-23   13.00    1575.80    1651.80   25.00      12.50     1.80      56.0     LOGT 06..
           GD-DHL 13.00X1650-35   13.00    1575.80    1651.80   25.00      12.50     1.80      56.0     LOGT 06..
          •  Note: Gundrills can be supplied with up to 2400 mm length on request.   •  Inserts and guide pads should be ordered separately (they are not included with the tools).
          •  For user guide and cutting conditions, see pages 289-292   •  Preventative measures: Do NOT operate the deep hole drill at full speed before engaging the guide hole.
          Enter the guide hole slowly at a speed of 50 - 100 rpm.
          For inserts, see pages: LOGT (288)
          GPS
          Deep Drilling Solid                                                             RE
          Carbide Guide Pads
                                                           W1
                                                                      INSL            S
                                                              Dimensions
           Designation             W1                RE                INSL                  S               IC908
           GPS-04-16-055           4.0               5.50              16.00                2.0             •
           Spare Parts
           Designation           Guide Pad Screw  Guide Pad Key  N*m
           GPS-04-16-055        TS 20043I/HG-P M2X0.4  Wrench IP-6/5  0.65
                                       Universal Marking for Deep Drilling Tools
                           D                                                            d1

                                                                              d2
                                                        L

                             D**.**       L***         d**         X**        XX





                                 D         L/D           d1          d2      Driver Type
         Example:                                                                  ******* [Lot no.]
         Metric: D14.00 L1000 d25X56WD
         Inch:    D0.551 L39.37 d0.984X2.205WD
                                                            *******
