INDEXABLE DRILLS MNC-5D 26.00 PL 132.93 2.93 DCONMS PDD 42.00 60.0 LS 166.92 DCONMS Insert (1) Insert 1 (2)
LPR
LU
Large Diameter Indexable Drills
with a Pilot Drilling Head and One
DF
DC PDD
Flat Shank, Drilling Depth 5xD
Designation
LPR
PL
DF
DC
LU
LS
32.00
SOGX 060304-W
ICP 150
MNC 260-130 A32-150-06-5D
15.00
MNC 265-132 A32-155-06-5D
SOGX 060304-W
135.53
15.50
167.03
ICP 155
3.03
42.00
26.50
32.00
60.0
MNC 270-135 A32-160-06-5D
42.00
16.00
60.0
27.00
32.00
ICP 160
3.10
170.10
138.10
SOGX 060304-W
MNC 280-140 A32-170-06-5D
28.00
32.00
3.25
17.00
174.30
60.0
SOGX 060304-W
ICP 170
143.25
42.00
MNC 290-145 A32-160-07-5D
3.19
42.00
SOGX 070305-W
MNC 295-148 A32-165-07-5D
ICP 165
150.69
29.50
32.00
16.50
183.21
60.0
42.00
30.00
ICP 165
60.0
153.19
16.50
SOGX 070305-W
186.21
MNC 300-150 A32-165-07-5D
32.00
3.19
158.34
193.30
60.0
ICP 175
SOGX 070305-W
32.00
3.34
42.00
17.50
MNC 310-155 A32-175-07-5D
31.00
MNC 320-160 A32-185-07-5D 29.00 148.10 3.10 32.00 16.00 42.00 60.0 180.11 SOGX 070305-W ICP 160
3.49
SOGX 070305-W
32.00
60.0
42.00
198.50
18.50
ICP 185
163.49
32.00
MNC 330-165 A32-175-09-5D 33.00 168.64 3.64 32.00 17.50 42.00 60.0 203.60 SOGT 09T306-W ICP 175
MNC 340-170 A32-180-09-5D 34.00 173.70 3.70 32.00 18.00 42.00 60.0 208.70 SOGT 09T306-W ICP 180
MNC 350-175 A32-189-09-5D 35.00 178.86 3.86 32.00 18.90 42.00 60.0 213.90 SOGT 09T306-W ICP 189
MNC 360-180 A32-190-10-5D 36.00 183.85 3.85 32.00 19.00 42.00 60.0 218.80 SOGT 100408-W ICP 190
MNC 370-185 A32-200-10-5D 37.00 189.01 4.01 32.00 20.00 42.00 60.0 224.00 SOGT 100408-W ICP 200
MNC 375-188 A32-205-10-5D 37.50 191.60 4.10 32.00 20.50 42.00 60.0 227.11 SOGT 100408-W ICP 205
MNC 380-190 A40-209-10-5D 38.00 194.17 4.17 40.00 20.90 50.00 68.0 231.21 SOGT 100408-W ICP 209
MNC 390-195 A40-215-10-5D 39.00 199.26 4.26 40.00 21.50 50.00 68.0 237.28 SOGT 100408-W ICP 215
MNC 400-200 A40-225-10-5D 40.00 204.41 4.41 40.00 22.50 50.00 68.0 244.36 SOGT 100408-W ICP 225
MNC 405-203 A40-235-10-5D 40.50 207.07 4.57 40.00 23.50 50.00 68.0 247.53 SOGT 100408-W ICP 235
MNC 410-205 A40-239-10-5D 41.00 209.64 4.64 40.00 23.90 50.00 68.0 249.64 SOGT 100408-W ICP 239
MNC 420-210 A40-249-10-5D 42.00 214.77 4.77 40.00 24.90 50.00 68.0 254.80 SOGT 100408-W ICP 249
MNC 430-215 A40-259-10-5D 43.00 219.99 4.99 40.00 25.90 50.00 68.0 263.00 SOGT 100408-W ICP 259
MNC 440-220 A40-210-12-5D 44.00 225.18 5.18 40.00 21.00 50.00 68.0 264.18 SOGT 120408-W ICP 210
MNC 450-225 A40-219-12-5D 45.00 230.33 5.33 40.00 21.90 50.00 68.0 269.38 SOGT 120408-W ICP 219
MNC 460-230 A40-229-12-5D 46.00 235.48 5.48 40.00 22.90 50.00 68.0 274.46 SOGT 120408-W ICP 229
MNC 470-235 A40-239-12-5D 47.00 240.64 5.64 40.00 23.90 50.00 68.0 280.63 SOGT 120408-W ICP 239
MNC 480-240 A40-249-12-5D 48.00 245.77 5.77 40.00 24.90 50.00 68.0 284.80 SOGT 120408-W ICP 249
MNC 490-245 A40-259-12-5D 49.00 250.99 5.99 40.00 25.90 50.00 68.0 292.00 SOGT 120408-W ICP 259
MNC 500-250 A40-269-12-5D 50.00 256.11 6.11 40.00 26.90 50.00 68.0 297.07 SOGT 120408-W ICP 269
• Hole tolerance: D+0.10/-0.05 in average conditions. However, it can be higher or lower according to machine and tooling conditions • Intermediate sizes are available on
request • For user guide and cutting conditions, see pages 68-81
(1) Outer insert
(2) Central insert
For inserts, see pages: HCP-IQ (47) • ICG (57) • ICP (18) • SOGT-W (67) • SOGX-W (67)
Spare Parts
Designation
MNC 260-130 A32-150-06-5D SR 34-508/L T-7/51 K MNC MULTI
MNC 265-132 A32-155-06-5D SR 34-508/L T-7/51 K MNC MULTI
MNC 270-135 A32-160-06-5D SR 34-508/L T-7/51 K MNC MULTI
MNC 280-140 A32-170-06-5D SR 34-508/L T-7/51 K MNC MULTI
MNC 290-145 A32-160-07-5D SR 14-560 T-8/53 K MNC MULTI
MNC 295-148 A32-165-07-5D SR 14-560 T-8/53 K MNC MULTI
MNC 300-150 A32-165-07-5D SR 14-560 T-8/53 K MNC MULTI
MNC 310-155 A32-175-07-5D SR 14-560 T-8/53 K MNC MULTI
MNC 320-160 A32-185-07-5D SR 14-560 T-8/53 K MNC MULTI
MNC 330-165 A32-175-09-5D SR 34-506 BLD T09/M7-SW4 SW4-SD K MNC MULTI
MNC 340-170 A32-180-09-5D SR 34-506 BLD T09/M7-SW4 SW4-SD K MNC MULTI
MNC 350-175 A32-189-09-5D SR 34-506 BLD T09/M7-SW4 SW4-SD K MNC MULTI
MNC 360-180 A32-190-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC MULTI
MNC 370-185 A32-200-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC MULTI
MNC 375-188 A32-205-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC MULTI
MNC 380-190 A40-209-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC MULTI
MNC 390-195 A40-215-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC MULTI
MNC 400-200 A40-225-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC 22-33
MNC 405-203 A40-235-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC 22-33
MNC 410-205 A40-239-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC 22-33
MNC 420-210 A40-249-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC 22-33
MNC 430-215 A40-259-10-5D SR 14-571 BLD T10/S7 SW6-SD K MNC 22-33
MNC 440-220 A40-210-12-5D SR 14-544/S BLD T15/S7 SW6-SD K MNC MULTI
MNC 450-225 A40-219-12-5D SR 14-544/S BLD T15/S7 SW6-SD K MNC MULTI
MNC 460-230 A40-229-12-5D SR 14-544/S BLD T15/S7 SW6-SD K MNC 22-33
MNC 470-235 A40-239-12-5D SR 14-544/S BLD T15/S7 SW6-SD K MNC 22-33
MNC 480-240 A40-249-12-5D SR 14-544/S BLD T15/S7 SW6-SD K MNC 22-33
MNC 490-245 A40-259-12-5D SR 14-544/S BLD T15/S7 SW6-SD K MNC 22-33
MNC 500-250 A40-269-12-5D SR 14-544/S BLD T15/S7 SW6-SD K MNC 22-33
