P. 84

INDEXABLE DRILLS  MD-BODY     DCONMS  MD-DR-DH  DCONWS  445.00  393.3  DCN (1)  LCF LF (2)  DCONWS (3)  SET SCREW M6-MODUDRILL BLD T15/S7  SW6-T-SH
                                       MD-DFN
                                                                                             LS
                                   DCN-DCX
          Modular Drill Bodies, Each
                                                                                                 DCONMS
                                                                                                       DF
          Can Carry a Variety of
          Exchangeable Drilling Heads
          with Different Diameters

                                                                     DCX
                                                         LCF
                                        DF
                                              LS
                                                    LF
           Designation
           MD-BODY-33-36-400-32A
                                                                             6.70
                                                                      36.90
                                       42.00
                                              60.0
                                 32.00
                                                               33.00
           MD-BODY-37-40-400-32A
                                                   445.00
                                                         393.3
                                                                                                          SW6-T-SH
                                                               37.00
                                       42.00
                                 32.00
                                              60.0
                                                                             6.90
                                                                      40.00
                                                                                  SET SCREW M6-MODUDRILL BLD T15/S7
          (1)  Cutting diameter minimum
          (2)  Cutting diameter maximum
          (3)  HEAD connection size
          For tools, see pages: MD-DFN-HEAD (82) • MD-DR-DH-HEAD (83)
          MODULAR DFN Assembly Options
          Holder                                 Head                  Pocket Range               CSI
                                             DFN 330 HEAD-09-39         33.00-33.90                8.5
                                             DFN 340 HEAD-09-39         34.00-34.90                8.5
          DFN 33-36-A32-8.5-HOLDER
                                             DFN 350 HEAD-09-39         35.00-35.90                8.5
                                             DFN 360 HEAD-09-39         36.00-36.90                8.5
                                             DFN 370 HEAD-10-39         37.00-37.90                9
          DFN 37-40-A32-9.5-HOLDER           DFN 380 HEAD-10-39         38.00-38.90                9
                                             DFN 390 HEAD-10-39         39.00-40.00                9

                                                            LPR

          MD-DFN-HEAD
          Exchangeable Drilling Heads
          Carrying CHAMIQDRILL                    DCN-DCX               DCONMS
          Solid Carbide Inserts
           Designation           DCN (1)   DCX (2)    LPR      DCONMS      PL       SSC (3)    MIID (4)
           MD-DFN 330 HEAD       33.00      33.90     36.90      6.70     7.330      33.0     HFP 330-IQ  K DFN  30-40
           MD-DFN 340 HEAD       34.00      34.90     37.20      6.70     7.620      34.0     HFP 340-IQ  K DFN  30-40
           MD-DFN 350 HEAD       35.00      35.90     37.20      6.70     7.650      35.0     HFP 350-IQ  K DFN  30-40
           MD-DFN 360 HEAD       36.00      36.90     37.60      6.70     8.150      36.0     HFP 360-IQ  K DFN  30-40
           MD-DFN 370 HEAD       37.00      37.90     37.60      6.90     8.040      37.0     HFP 370-IQ  K DFN  30-40
           MD-DFN 380 HEAD       38.00      38.90     38.00      6.90     8.200      38.0     HFP 380-IQ  K DFN  30-40
           MD-DFN 390 HEAD       39.00      40.00     38.00      6.90     8.430      39.0     HFP 390-IQ  K DFN  30-40
          •  Do not mount smaller drilling heads other than the specified range of the drill body   •  For user guide and cutting conditions, see pages 84-85
          (1)  Cutting diameter minimum
          (2)  Cutting diameter maximum
          (3)  Seat size code
          (4)  Master insert identification
          For inserts, see pages: HFP-IQ (87)
          For holders, see pages: MD-BODY (82) • MD-EXTENSION (83)
