P. 88

INDEXABLE DRILLS  DFN A-1.5D-IQ     DCN (1)  DCX (2)  DCONMS  DCN-DCX k7   50.0  LU  LPR LPR OAL  7.330  DCONMSh6 DF  SSC (3)  K DFN  30-40
                                                                               LS
          Exchangeable Head Drills with
          Flat Shank and Internal Coolant
          Holes. Drilling Depth: 1.5xD
                                                                PL



                                                                              PL
                                                                                     LS
                                                        DF
                                                               LU
           Designation
                                                                                            OAL
           DFN 330-050-32A-1.5D-IQ
                                                                      87.5
                                                                                     60.0
                                                       42.00
                                         33.90
                                  33.00
                                                32.00
                                                                                                    33.0
                                                                                            147.50
           DFN 340-051-32A-1.5D-IQ
                                  34.00
                                                                                     60.0
                                                                      90.2
                                         34.90
                                                                                            150.20
                                                                             7.620
                                                       42.00
                                                                                                    34.0
                                                              51.0
                                                                                                         K DFN  30-40
                                                32.00
           DFN 350-053-32A-1.5D-IQ
                                                32.00
                                                                                                    35.0
                                                              53.0
                                                                                     60.0
                                         35.90
                                                                                                         K DFN  30-40
                                                                                            152.80
                                                       42.00
                                                                      92.8
                                                                             7.650
                                  35.00
                                         36.90
                                  36.00
                                                32.00
                                                                             8.150
                                                              54.0
                                                                      95.5
           DFN 360-054-32A-1.5D-IQ
                                                                                     60.0
                                                       42.00
                                                                      98.1
                                                                             8.040
                                                                                            158.10
                                                                                                    37.0
                                                                                                         K DFN  30-40
                                                32.00
                                                       42.00
                                                                                     60.0
                                         37.90
                                                              56.0
                                  37.00
           DFN 370-056-32A-1.5D-IQ
                                                                             8.200
                                                32.00
                                                                                     60.0
           DFN 380-057-32A-1.5D-IQ
                                                              57.0
                                                       42.00
                                                                     100.8
                                                                                                    38.0
                                                                                                         K DFN  30-40
                                         38.90
                                  38.00
                                                                                            160.80
                                                                                                    39.0
                                                              59.0
           DFN 390-059-32A-1.5D-IQ
                                                                     103.4
                                                                             8.430
                                                                                     60.0
                                                                                            163.40
                                  39.00
                                                                                                         K DFN  30-40
                                         40.00
                                                       42.00
                                                32.00
          •  Do not mount smaller drilling heads other than the specified range of the drill body   •  For user guide and cutting conditions, see pages 89-91 155.50  36.0  K DFN  30-40
          (1)  Cutting diameter minimum
          (2)  Cutting diameter maximum
          (3)  Seat size code
          For inserts, see pages: HFP-IQ (87)

                                                                       OAL

          DFN A-3D-IQ                                           LU  LPR              LS
          Exchangeable Head Drills with
          Flat Shank and Internal Coolant     DCN-DCX k7                                   DCONMSh6  DF
          Holes. Drilling Depth: 3xD
                                                        PL
           Designation         DCN (1)  DCX (2)  DCONMS  DF   LU     LPR     PL      LS     OAL    SSC (3)
           DFN 330-099-32A-3D-IQ  33.00  33.90  32.00  42.00  99.0   137.0   7.330   60.0  197.00   33.0  K DFN  30-40
           DFN 340-102-32A-3D-IQ  34.00  34.90  32.00  42.00  102.0  141.2   7.620   60.0  201.20   34.0  K DFN  30-40
           DFN 350-105-32A-3D-IQ  35.00  35.90  32.00  42.00  105.0  145.3   7.650   60.0  205.30   35.0  K DFN  30-40
           DFN 360-108-32A-3D-IQ  36.00  36.90  32.00  42.00  108.0  149.5   8.150   60.0  209.50   36.0  K DFN  30-40
           DFN 370-111-32A-3D-IQ  37.00  37.90  32.00  42.00  111.0  153.6   8.040   60.0  213.60   37.0  K DFN  30-40
           DFN 380-114-32A-3D-IQ  38.00  38.90  32.00  42.00  114.0  157.8   8.200   60.0  217.80   38.0  K DFN  30-40
           DFN 390-117-32A-3D-IQ  39.00  40.00  32.00  42.00  117.0  161.9   8.430   60.0  221.90   39.0  K DFN  30-40
          •  Do not mount smaller drilling heads other than the specified range of the drill body   •  For user guide and cutting conditions, see pages 89-91
          (1)  Cutting diameter minimum
          (2)  Cutting diameter maximum
          (3)  Seat size code
          For inserts, see pages: HFP-IQ (87)

                                                                       OAL
          DFN A-5D-IQ                                              LPR               LS
          Exchangeable Head Drills with                         LU
          Flat Shank and Internal Coolant     DCN-DCX k7                                   DCONMSh6  DF
          Holes. Drilling Depth: 5xD
                                                        PL
           Designation          DCN (1)  DCX (2)  DCONMS  DF   LU     LPR     PL     LS     OAL    SSC (3)
           DFN 330-165-32A-5D-IQ  33.00  33.90  32.00  42.00  165.0  203.0   7.330   60.0   263.00  33.0  K DFN  30-40
           DFN 340-170-32A-5D-IQ  34.00  34.90  32.00  42.00  170.0  209.2   7.620   60.0   269.20  34.0  K DFN  30-40
           DFN 350-175-32A-5D-IQ  35.00  35.90  32.00  42.00  175.0  215.3   7.650   60.0   275.30  35.0  K DFN  30-40
           DFN 360-180-32A-5D-IQ  36.00  36.90  32.00  42.00  180.0  221.5   8.150   60.0   281.50  36.0  K DFN  30-40
           DFN 370-185-32A-5D-IQ  37.00  37.90  32.00  42.00  185.0  227.6   8.040   60.0   287.60  37.0  K DFN  30-40
           DFN 380-190-32A-5D-IQ  38.00  38.90  32.00  42.00  190.0  233.8   8.200   60.0   293.80  38.0  K DFN  30-40
           DFN 390-195-32A-5D-IQ  39.00  40.00  32.00  42.00  195.0  239.9   8.430   60.0   299.90  39.0  K DFN  30-40
          •  Do not mount smaller drilling heads other than the specified range of the drill body   •  For user guide and cutting conditions, see pages 89-91
          (1)  Cutting diameter minimum
          (2)  Cutting diameter maximum
          (3)  Seat size code
          For inserts, see pages: HFP-IQ (87)
