GROOVE-TURN GAIR/L DMIN CWN (1) CWN-CWX CWX (2) GIPI/GIFI.. DMIN Right-hand shown
LF
Internal Grooving and
Turning Adapters

WB
CDX
WB
Designation
LF
CDX
(3)
1.50
32.00
GAIR/L 32-2
3.80
2.10
3.00
1.20
GAIR/L 32-3
4.10
3.00
2.10
1.80
3.00
32.00
GAIR/L 32-4
GAIR/L 32-5
5.00
4.00
6.40
32.00
5.20
4.50
GAIR/L 40-2
1.50
1.20
3.80
3.00
2.10
40.00
1.80
3.00
2.10
4.10
4.00
40.00
GAIR/L 40-3 32.00 3.00 4.50 5.00 4.50 2.50
GAIR/L 40-4 40.00 3.00 4.50 7.00 4.50 2.50
GAIR/L 40-5 40.00 4.50 6.40 7.00 5.20 4.00
• When using TIPI inserts, toolholder seat needs to be modified according to insert profile to ensure clearance • For user guide, see pages 419-428, 432-436
(1) Minimum cutting width
(2) Maximum cutting width
(3) Cutting depth maximum
For inserts, see pages: GIMIY (332) • GIPI-E (333) • GIFI-E (333) • GIFI-E (full radius) (333) • GINI-E (334) • GIPI (W<M) (334)
• GIPI (335) • GIPI (full radius W<M) (335) • GIPI (full radius) (336) • GIFI (336) • GIPI-RX/LX (336) • TIPI-MT (337) • TIPI-WT (337)
For holders, see pages: C#-GHAIR/L (629) • GHAIR/L-GI (331)

GHIC-50 DCONMS H
Boring Bars for Internal
Grooving and Turning B
Blades, DMIN=50 mm
HF
OAL
Designation H DCONMS OAL HF B
GHIC 32-50 26.0 32.00 220.00 14.5 29.0 SR M5X16 DIN912 HW 4.0
GHIC 40-50 26.0 40.00 260.00 18.0 36.0 SR M5X16 DIN912 HW 4.0
• For both right and left hand applications
For tools, see pages: CGIN 26 (348)

LF View A
AVC-GEAIR/L CDX A BAWS
Internal Grooving, Turning
and Threading Adapters WB
DMIN
WF
DCONMS
CWN-CWX Right-hand shown
Designation DMIN CWN (1) CWX (2) DCONMS CDX (3) WF LF WB BAWS MIID (4)
AVC-D16-GEAIR/L-2 21.00 1.90 2.40 16.00 3.00 12.00 14.50 1.60 45 GEPI 2.00-0.10
AVC-D16-GEAIR/L-3 21.00 2.40 2.70 16.00 3.00 12.00 14.50 2.00 45 GEPI 3.00-0.20
AVC-D20-GEAIR/L-2 26.00 1.90 2.40 20.00 3.00 14.70 13.50 1.60 15 GEPI 2.00-0.10
AVC-D20-GEAIR/L-3 26.00 2.40 3.18 20.00 3.00 14.70 13.50 2.00 15 GEPI 3.00-0.20
AVC-D25-GEAIR/L-2 31.00 1.90 2.40 25.00 4.00 17.50 17.50 1.60 15 GEPI 2.00-0.10
AVC-D25-GEAIR/L-3 31.00 2.40 3.18 25.00 4.00 17.50 17.50 2.00 15 GEPI 3.00-0.20
• Using the adapters with CAMFIX holders is only possible in case the machine has an option for rotating the CAMFIX Axis.
• For user guide, see pages 419-428, 432-436
(1) Minimum cutting width
(2) Maximum cutting width
(3) Cutting depth maximum
(4) Master insert identification
For inserts, see pages: GEMI (341) • GEMI (full radius) (341) • GEPI (342) • GEPI (full radius) (342) • GEPI-MT (648) • GEPI-WT (642)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)

Spare Parts
Designation
AVC-D16-GEAIR/L-2 SR 14-551 T-9/5
AVC-D16-GEAIR/L-3 SR 14-551 T-9/5
AVC-D20-GEAIR/L-2 SR 34-510 SW6-SD BLD T15/M7
AVC-D20-GEAIR/L-3 SR 34-510 SW6-SD BLD T15/M7
AVC-D25-GEAIR/L-2 SR M4X14 DIN912 HW 3.0
AVC-D25-GEAIR/L-3 SR M4X14 DIN912 HW 3.0
