Page 346 - ISCAR(TURNING-CATALOG-42-2022)

GROOVE-TURN GHIR/L (W=1.9-6.4) CWN (1) CWX (2) DCONMS DMIN WF CDX (3) LDRED 160.00 LDRED 14.50 Right-hand shown
CDX
HF
WB
Internal Grooving and Turning Bars
OAL
DCONMS
CWN-CWX
DMIN
Designation
OAL
WB
HF
WF
3.50
1.90
1.55
20.00
4.50
16.0
9.0
20.00
GHIR/L 20-3
GHIR/L 20-20-3
4.50
14.50
40.0
200.00
20.00
1.60
9.0
3.50
2.00
20.00
GHIR/L 20-4
9.0
GHIR/L 20-20-4
20.00
3.00
4.80
2.60
20.00
40.0
200.00
9.0
14.50
4.50
17.50
2.10
25.00
50.0
200.00
5.00
4.00
25.00
GHIR/L 25-25-4
2.50
32.00
38.00
-
250.00
5.00
14.5
2.50
2.10
GHIR/L 32-4 3.00 4.80 20.00 20.00 4.50 160.00 25.0 14.50 11.5 2.60
4.00
21.30
GHIR/L 25-5 3.20 5.30 25.00 26.00 6.00 160.00 25.0 18.50 11.5 2.80
GHIR/L 25-25-6 4.00 6.40 25.00 25.00 5.00 200.00 50.0 17.50 11.5 3.60
GHIR/L 32-6 4.00 6.40 32.00 39.00 6.50 250.00 - 22.80 14.5 3.60
GHIR/L 40-6 4.00 6.40 40.00 49.00 8.00 300.00 - 28.30 18.0 3.60
• When using TIPI inserts, toolholder seat needs to be modified according to insert profile to ensure clearance. • For user guide, see pages 419-428, 432-436
(1) Minimum cutting width
(2) Maximum cutting width
(3) Cutting depth maximum
For inserts, see pages: GIFI (352) • GIFI-E (349) • GIFI-E (full radius) (350) • GIMIY (349) • GINI-E (350) • GIPI (351)
• GIPI (full radius W<M) (351) • GIPI (full radius) (352) • GIPI (W<M) (350) • GIPI-E (349) • GIPI-RX/LX (352) • TIPI-MT (648) • TIPI-WT (642)

Spare Parts
Designation
GHIR/L 20-3 SR 76-1021 T-20/5
GHIR/L 20-20-3 SR 76-1021 T-20/5
GHIR/L 20-4 SR 76-1021 T-20/5
GHIR/L 20-20-4 SR 76-1021 T-20/5
GHIR/L 25-25-4 SR 76-1022 T-20/5
GHIL 32-4 SR 76-1021 T-20/5
GHIR 32-4 SR 76-1022 T-20/5
GHIR/L 25-5 SR 76-1022 T-20/5
GHIR/L 25-25-6 SR 76-1022 T-20/5
GHIR/L 32-6 SR 76-1022 T-20/5
GHIL 40-6 SR 76-1022 T-20/5
GHIR 40-6 SR 76-1021 T-20/5

GHIR/L-C (W=4-6.4) LDRED
Grooving and Turning Bars CDX DCONMS
with Internal Coolant Holes DMIN WF WB
CWN-CWX HF
OAL
Right-hand shown
Designation DCONMS CWN (1) CWX (2) DMIN CDX (3) HF OAL LDRED WF WB Inlet
GHIR/L 25C-510 25.00 4.00 5.30 32.00 10.00 11.5 160.00 25.0 22.50 3.50 R1/8 SR 76-1022 T-20/5 PL 25
GHIR/L 32C-610 32.00 4.80 6.40 43.00 10.00 14.5 200.00 - 26.20 4.40 R1/8 SR 76-1022 T-20/5 PL 32
GHIR/L 40C-612 40.00 4.80 6.40 53.00 12.00 18.0 250.00 - 32.20 4.40 R1/8 SR 76-1022 T-20/5 PL 40
• When using TIPI inserts, toolholder seat needs to be modified according to insert profile to ensure clearance. • For user guide, see pages 419-428, 432-436
(1) Minimum cutting width
(2) Maximum cutting width
(3) Cutting depth maximum
For inserts, see pages: GIFI (352) • GIFI-E (349) • GIFI-E (full radius) (350) • GIMIY (349) • GINI-E (350) • GIPI (351)
• GIPI (full radius) (352) • GIPI-E (349) • TIPI-MT (648)
