HSSE DIN 374
MF ISO DIN 13

N410 3 N420 4 N420V 4 N420TN 4

N

N410-3 31 62 73 74 91

62 63 72 73 74
N420-4
81 91

N420V-4 V 11 12 31 32

< 1.5 x D

N420TN-4 TiN 11 12 13 14 32

a C B B B
d 2
2.5 x P 4 x P 4 x P 4 x P
d 1
l 2
l
1 P
Ø d 1 P l 1 l 2 d 2 a ID ID ID ID
MF mm mm mm mm mm
* 4 0.35 63 14 2.8 2.1 3 3.65 l 142695
4 0.5 63 14 2.8 2.1 3 3.5 l 101923 l 102145 l 142715
4.5 0.5 70 15 3.5 2.7 3 4 l 102150
5 0.5 70 15 3.5 2.7 3 4.5 l 101941 l 102167 l 142716
5 0.75 70 15 3.5 2.7 3 4.25 l 102168
5.5 0.5 80 17 4 3 3 5 l 142696
6 0.5 80 17 4.5 3.4 3 5.5 l 101951 l 102178 l 142717
6 0.75 80 17 4.5 3.4 3 5.25 l 101952 l 102179 l 102281 l 102249
7 0.5 80 17 5.5 4.3 3 6.5 l 102187
7 0.75 80 17 5.5 4.3 3 6.25 l 101954 l 102188
8 0.5 90 20 6 4.9 3 7.5 l 101955 l 102190 l 142718
8 0.75 90 20 6 4.9 3 7.25 l 101956 l 102191 l 102283
8 1 90 20 6 4.9 3 7 l 101957 l 102192 l 102284 l 102250
9 0.5 90 20 7 5.5 3 8.5 l 142697
9 0.75 90 20 7 5.5 3 8.25 l 102200
9 1 90 20 7 5.5 3 8 l 102201 l 143935
10 0.5 100 22 7 5.5 3 9.5 l 142698
10 0.75 100 22 7 5.5 3 9.25 l 101863 l 102056
10 1 100 22 7 5.5 3 9 l 101864 l 102057 l 102262 l 102239
10 1.25 100 22 7 5.5 3 8.8 l 101865 l 102058 l 142719 l 148108

*N420-3 2.5 x P
