Page 180 - DC_SWISS(Catalogue_TM_ES-EN)

UNF ASME B1.1 HSSE DIN 374

N410 3 N420 4 N420V 4 N420TN 4

N

N410-3 31 62 73 74 91

62 63 72 73 74
N420-4
81 91

NEW
N420V-4 V 11 12 31 32 NEW

< 1.5 x D

N420TN 4 TiN 11 12 13 14 32

a C B B B
d 2
2.5 x P 4 x P 4 x P 4 x P
d 1
l 2
l
1 P
Ø’’ d 1 P d 1 l 1 l 2 d 2 a ID ID ID ID
UNF TPI mm mm mm mm mm
5/16 24 7.93 90 20 6 4.9 3 6.9 l 102004 l 102223 l 142774 l 196015
3/8 24 9.52 100 22 7 5.5 3 8.5 l 102003 l 102222 l 142775 l 196016
7/16 20 11.11 100 19 8 6.2 3 9.8 l 102006 l 102225 l 142776 l 196017
1/2 20 12.7 100 24 9 7 3 11.4 l 102000 l 102219 l 142777 l 196018
9/16 18 14.28 100 24 11 9 3 12.9 l 102227
5/8 18 15.87 100 26 12 9 3 14.5 l 102005 l 102224 l 142778 l 196019
3/4 16 19.05 125 33 14 11 4 17.5 l 102002 l 102221 l 142779 l 185919
7/8 14 22.22 140 36 18 14.5 4 20.4 l 102226
1 12 25.4 160 39 18 14.5 4 23.3 l 102220 l 142780
1 1/8 12 28.57 180 39 22 18 4 26.5 l 142773
1 1/4 12 31.75 180 39 22 18 4 29.7 l 102218
1 3/8 12 34.92 200 36 28 22 4 32.8 l 105137
1 1/2 12 38.1 200 41 32 24 4 36 l 105138

Ø’’ d 1 P d 1 l 1 l 2 d 2 a UNJF ID
UNF TPI mm mm mm mm mm
5/16 24 7.93 90 20 6 4.9 3 7 l 155328
3/8 24 9.52 100 22 7 5.5 3 8.6 l 155326
7/16 20 11.11 100 19 8 6.2 3 10 l 155330
1/2 20 12.7 100 24 9 7 3 11.55 l 155321
