SRT Mandril de roscar con amortiguador axial SYNCHRO Uniquement pour taraudage synchrone
Nur für Sychronbearbeitung
Only for rigid tapping
Solo per maschiatura sincrona
Tapping chucks with axial shock absorber
Solo para roscado sincronizado
Только для ridgid tapping
DIN 1835 B SRT032•D6 SRT054•D12 ER8
nano

SRT032 / SRT054 D9865-

D D D L L L
mm mm 1 mm 2 mm mm 1 mm 2 ID ID
M0.3 - M2 12 11 6 25 40 56 l 157610
M0.5 - M4 12 20 12 33 59 75 l 127413

No D L d ID
mm 2 mm 3 mm 2
ER8-0100 8.5 13.5 1 l 179401
ER8-0150 8.5 13.5 1.5 l 179400
ER8-0200 8.5 13.5 2 l 118895
ER8-0250 8.5 13.5 2.5 l 118896
ER8-0300 8.5 13.5 3 l 118897
ER8-0350 8.5 13.5 3.5 l 118898
ER8-0400 8.5 13.5 4 l 118899
ER8-0450 8.5 13.5 4.5 l 118900

DIN 1835 B SRT312•D20 SRT312•D25 SRT520•D25

short

L

D 1 D 2

L 1

D D L L &
mm 1 mm 2 mm mm 1 310 ID ID ID
M3 - M12 39 20 47 86 S1 l 162832
M3 - M12 39 25 53 90 S1 l 162831
M5 - M20 56 25 53 110 S2 l 162833
