VHM DC
SF NIHS 06-10 Fine Thread CLASSIC SYNCHRO CAR

CMS CMS50 CMS50VS

CMS50 62 63 93
R12

CMS50VS VS 31 62 63 73 74 83
R12 93

< 3 x D < 3 x D

C C
2.5 x P 2.5 x P
d 2
d 1
l
2 NIHS NIHS
l
1 P
Ø d 1 P l 1 l 2 d h5 ID ID
2
SF mm mm mm mm
1.4 0.2 32 5.2 2 3 ∆ 1.26 l 180329 l 193694
1.6 0.2 32 6 2 3 ∆ 1.46 l 193632 l 193695
1.8 0.2 32 6.7 2 3 ∆ 1.66 l 193633 l 193696
2 0.2 39 7.5 3 3 ∆ 1.86 l 193634 l 193697
2.2 0.2 39 8.2 3 3 ∆ 2.06 l 193635 l 193698
2.2 0.25 39 8.2 3 3 ∆ 2.02 l 193636 l 193699
2.5 0.2 39 9.3 3 3 ∆ 2.36 l 193637 l 193700
2.5 0.25 39 9.3 3 3 ∆ 2.32 l 193638 l 193701
∆
4H5H 4H6H = +0.02 mm
