PM DC
S NIHS 06-10 CLASSIC SYNCHRO

TAZ TAZ40 TAZ40VS TAZ50 TAZ50VS

TAZ40
L20

TAZ40VS VS 21 22 23 41 42 61
L20

TAZ50
R25
< 2 x D < 2 x D < 2 x D < 2 x D

TAZ50VS VS 21 22 23 41 42 61
R25

D D C C
d 2 4 x P 4 x P 2 x P 2 x P
d 1
l
2 NIHS NIHS NIHS NIHS
l
1 P
Ø d 1 P l 1 l 2 d 2 ID ID ID ID
S mm mm mm mm
0.5 0.125 25 1.5 2 3 ∆ 0.41 l 193978 l 194043 l 194103 l 194168
0.6 0.15 25 1.8 2 3 ∆ 0.5 l 193979 l 194044 l 194104 l 194169
0.7 0.175 25 2.1 2 3 ∆ 0.58 l 193980 l 194045 l 194105 l 194170
0.8 0.2 25 2.4 2 3 ∆ 0.66 l 193981 l 194046 l 194106 l 188515
0.9 0.225 25 2.7 2 3 ∆ 0.74 l 193982 l 194047 l 194107 l 188521
1 0.25 40 3 2.5 3 ∆ 0.82 l 193983 l 194048 l 194108 l 194171
1.2 0.25 40 3.6 2.5 3 ∆ 1.02 l 193984 l 194049 l 194109 l 194172
1.4 0.3 40 4.2 2.5 3 ∆ 1.18 l 193985 l 194050 l 194110 l 194173

∆
4H5H 4H6H = +0.02 mm
