UNF ASME B1.1 CLASSIC SYNCHRO PM DC – DIN 371

TAZ TAZ40 TAZ40VS TAZ50 TAZ50VS

TAZ40
L20

TAZ40VS VS 21 22 23 41 42 61
L20

TAZ50
R25
< 2 x D < 2 x D < 2 x D < 2 x D

TAZ50VS VS 21 22 23 41 42 61
R25

D D C C
4 x P 4 x P 2 x P 2 x P
d 2
a
d 1
l 2
l P
1
Ø d 1 P d 1 l 1 l 2 d 2 a ID ID ID ID
UNF TPI mm mm mm mm mm
0 80 1.52 40 4.6 2.5 3 1.2 l 194027 l 194087 l 194152 l 194210
1 72 1.85 40 5.6 2.5 3 1.5 l 194028 l 194088 l 194153 l 194211
2 64 2.18 45 9 2.8 2.1 3 1.8 l 194029 l 194089 l 194154 l 194212
3 56 2.51 50 10 2.8 2.1 3 2.1 l 194030 l 194090 l 194155 l 194213

d 2 a
d 1
l
2
l
1 P
Ø d 1 P d 1 l 1 l 2 d 2 a ID ID ID ID
UNF(J) TPI mm mm mm mm mm
0 80 1.52 40 4.6 2.5 3 1.2 l 194031 l 194091 l 194156 l 194214
1 72 1.85 40 5.6 2.5 3 1.5 l 194032 l 194092 l 194157 l 194215
2 64 2.18 45 9 2.8 2.1 3 1.8 l 194033 l 194093 l 194158 l 194216
3 56 2.51 50 10 2.8 2.1 3 2.1 l 194034 l 194094 l 194159 l 194217
