VHM DC
MF ISO DIN 13 CLASSIC SYNCHRO CAR

CMS CMS50 CMS50VS

CMS50 62 63 93
R12

CMS50VS VS 31 62 63 73 74 83
R12 93

< 3 x D < 3 x D

C C
2.5 x P 2.5 x P
d 2
d 1
l
2
l
1 P
Ø d 1 P l 1 l 2 d h5 ID ID
2
MF mm mm mm mm
1.4 0.2 32 5.2 2 3 1.2 l 193656 l 193719
1.6 0.2 32 6 2 3 1.4 l 193657 l 193720
1.8 0.2 32 6.7 2 3 1.6 l 193658 l 193721
2 0.2 39 7.5 3 3 1.8 l 193659 l 193722
2 0.25 39 7.5 3 3 1.75 l 193660 l 193723
2.2 0.2 39 8.2 3 3 2 l 193661 l 193724
2.2 0.25 39 8.2 3 3 1.95 l 193662 l 193725
2.3 0.2 39 8.6 3 3 2.1 l 193663 l 193726
2.3 0.25 39 8.6 3 3 2.05 l 193664 l 193727
2.5 0.2 39 9.3 3 3 2.3 l 193665 l 193728
2.5 0.25 39 9.3 3 3 2.25 l 193666 l 193729

d 2
d 1
l
2
l
1 P
Ø d 1 P l 1 l 2 d h5 ID ID
2
MF mm mm mm mm
2.5 0.35 39 9.3 3 3 2.15 l 193667 l 193730
2.6 0.35 39 9.7 3 3 2.25 l 193668 l 193731
