ISO DIN 13 VHM
M ISO DIN 14 CLASSIC SYNCHRO CAR DC

CMS CMS50 CMS50VS

CMS50 62 63 93
R12

CMS50VS VS 31 62 63 73 74 83
R12 93

< 3 x D < 3 x D

C C
2.5 x P 2.5 x P
d 2
d 1
l
2 4H 4H
l
1 P
Ø d 1 P l 1 l 2 d h5 ID ID
2
M mm mm mm mm
0.3 0.08 32 1.1 1.5 3 0.23 l 193639 l 193702
0.35 0.09 32 1.3 1.5 3 0.28 l 193640 l 193703
0.4 0.1 32 1.5 1.5 3 ∆ 0.32 l 193641 l 193704
0.5 0.125 32 1.8 1.5 3 ∆ 0.41 l 193642 l 193705
0.6 0.15 32 2.2 1.5 3 ∆ 0.5 l 193643 l 193706
0.7 0.175 32 2.6 1.5 3 ∆ 0.58 l 193644 l 193707
0.8 0.2 32 3 1.5 3 ∆ 0.66 l 193645 l 193708
0.9 0.225 32 3.3 1.5 3 ∆ 0.74 l 193646 l 193709
1 0.25 32 3.7 2 3 0.75 l 193647 l 193710
1.2 0.25 32 4.5 2 3 0.95 l 193648 l 193711
1.4 0.3 32 5.2 2 3 1.1 l 193649 l 193712

∆
4H5H 4H6H = +0.02 mm ≥ M1 - ≤ M1.4

d 2
d 1
l
2
l 1 P
Ø d 1 P l 1 l 2 d h5 ID ID
2
M mm mm mm mm
1.6 0.35 32 6 2 3 1.25 l 193650 l 193713
1.8 0.35 32 6.7 2 3 1.45 l 193651 l 193714
2 0.4 39 7.5 3 3 1.6 l 193652 l 193715
2.3 0.4 39 8.6 3 3 1.9 l 193653 l 193716
2.5 0.45 39 9.3 3 3 2.05 l 193654 l 193717
2.6 0.45 39 9.7 3 3 2.15 l 193655 l 193718
