Directorio ‘ Calibres de control NANO para micromecánica y relojeria
Directory ¬ Thread gauges NANO for micromechanics and watchmaking

Calibres tampon Calibres anillos Contra calibres
Thread plug gauges Thread ring gauges Plug check gauges
Características
Characteristics

Tipo DN01 DN01 DN02 DZ04 DZ14 DN04 DN14 RN05-1 RN15-1 RN05-2 RN15-2
Type GO GO NO-GO GO NO-GO GO NO-GO GO GO NO-GO NO-GO

M 4H / 5h ISO DIN 14 382 382 383 383 384 384 399 399 400 400
ISO DIN 13
M 6H / 6g ISO DIN 13 382 382 383 383 384 384 399 399 400 400

M 5H / 6h ISO DIN 13 382 382 383 383 384 384 399 399 400 400
MF 4H / 4h ISO DIN 13 385 385 386 386 387 387 402 402 403 403
MF 6H / 6g ISO DIN 13 385 385 386 386 387 387 402 402 403 403
MF 6h ISO DIN 13 386 386 387 387 402 402 403 403

UNC 2B / 2A ASME B1.1 388 388 389 389 390 390 405 405 406 406
UNC 3B / 3A ASME B1.1 388 388 389 389 390 390 405 405 406 406
UNF 2B / 2A ASME B1.1 388 388 389 389 390 390 405 405 406 406

UNF 3B / 3A ASME B1.1 388 388 389 389 390 390 405 405 406 406
S NIHS 3G NIHS 391
S NIHS 4H NIHS 391
S NIHS 4H / 3G NIHS 391

S NIHS NIHS 393 393 394 394 407 407 408 408
S NIHS NT NIHS 392 392 393 393 394 394 407 407 408 408

SF NIHS 3G NIHS 395
SF NIHS 4H NIHS 395
SF NIHS 4H / 3G NIHS 395
SF NIHS NIHS 396 396 397 397 409 409 410 410

SF NIHS NT NIHS 409 409 410 410
SL SL 15-01 398 398
