~ DIN 371 (d2 h6)
PM
MJ ISO 5855 DIN 371 DIN 371

Z S320VS«4 S370VX«3 SA390«3
S

S320VS-4 VS 13 15 16 22
23 24 52

S370VX-3 VX 15 22 23 24
R45 CLASSIC SYNCHRO 51 52 61

≤ 2.5 x D < 1.5 x D

SA390-3 16 53
R10
< 1.5 x D

B C C
a
d 2
4 x P 2.5 x P 2.5 x P
d 1
l
2
l 3 l
1 P
Ø d 1 P l 1 l 2 l 3 d 2 a ID
MJ mm mm mm mm mm mm
3 0.5 56 12 18 3.5 2.7 3 2.55 l 198966
4 0.7 63 14 21 4.5 3.4 3 3.4 l 198967
5 0.8 70 15 25 6 4.9 3 4.3 l 198968
6 1 80 17 30 6 4.9 3 5.1 l 198969
8 1 90 20 35 8 6.2 3 7.1 l 198970
8 1.25 90 20 35 8 6.2 3 6.9 l 198971
10 1.25 100 22 39 10 8 3 8.9 l 198972
10 1.5 100 22 39 10 8 3 8.6 l 198973
Ø d 1 P l 1 l 2 l 3 d h6 a ID
2
MJ mm mm mm mm mm mm
3 0.5 56 5.5 18 3.5(h9) 2.7 3 2.55 l 198974
4 0.7 63 7.5 21 4.5(h9) 3.4 3 3.4 l 198975
5 0.8 70 9 25 6 4.9 3 4.3 l 198976
6 1 80 11 30 6 4.9 3 5.1 l 198977
8 1 90 12.5 35 8 6.2 3 7.1 l 198978
8 1.25 90 12.5 35 8 6.2 3 6.9 l 198979
10 1.25 100 14 39 10 8 3 8.9 l 198980
10 1.5 100 14 39 10 8 3 8.6 l 198981
Ø d 1 P l 1 l 2 d 2 a ID
MJ mm mm mm mm mm
3 0.5 56 12 3.5 2.7 3 2.55 l 199006
4 0.7 63 14 4.5 3.4 3 3.4 l 199007
5 0.8 70 15 6 4.9 3 4.3 l 199008
6 1 80 20 6 4.9 3 5.1 l 199009
8 1 90 25 8 6.2 3 7.1 l 199010
8 1.25 90 25 8 6.2 3 6.9 l 199011
10 1.25 100 30 10 8 3 8.9 l 199012
10 1.5 100 30 10 8 3 8.6 ≤MJ5x0.8 = l 199013
