UNJF ISO 3161/ASME B1.15 PM DIN 371 ~ DIN 371 (d2 h6)

DIN 371

Z S320VS«4 S370VX«3 SA390«3
S

S320VS-4 VS 13 15 16 22
23 24 52

S370VX-3 VX 15 22 23 24
R45 CLASSIC SYNCHRO 51 52 61

≤ 2.5 x D < 1.5 x D

SA390-3 16 53
R10
< 1.5 x D

B C C
a
d 2
4 x P 2.5 x P 2.5 x P
d 1
l
2
l 3 l
1 P
Ø’’ d 1 P d 1 l 1 l 2 l 3 d 2 a ID
UNJF TPI mm mm mm mm mm mm
10 32 4.82 70 15 25 6 4.9 3 4.1 l 199038
1/4 28 6.35 80 17 30 7 5.5 3 5.55 l 199039
5/16 24 7.93 90 20 35 8 6.2 3 7 l 199040
3/8 24 9.52 100 22 39 10 8 3 8.6 l 199041

Ø’’ d 1 P d 1 l 1 l 2 l 3 d h6 a ID
2
UNJF TPI mm mm mm mm mm mm
10 32 4.82 70 9 25 6 4.9 3 4.1 l 197707
1/4 28 6.35 80 11 30 6 4.9 3 5.55 l 197708
5/16 24 7.93 90 12.5 35 8 6.2 3 7 l 197709
3/8 24 9.52 100 14 39 10 8 3 8.6 l 197710

Ø’’ d 1 P d 1 l 1 l 2 d 2 a ID
UNJF TPI mm mm mm mm mm
10 32 4.82 70 15 6 4.9 3 4.1 l 199049
1/4 28 6.35 80 20 7 5.5 3 5.55 l 199050
5/16 24 7.93 90 25 8 6.2 3 7 l 199051
3/8 24 9.52 100 30 10 8 3 8.6 l 199052
