UNJC ISO 3161/ASME B1.15 PM DIN 371 ~ DIN 371 (d2 h6)

DIN 371

Z S320VS«4 S370VX«3 SA390«3
S

S320VS-4 VS 13 15 16 22
23 24 52

S370VX-3 VX 15 22 23 24
R45 CLASSIC SYNCHRO 51 52 61

≤ 2.5 x D < 1.5 x D

SA390-3 16 53
R10
< 1.5 x D

B C C
a
d 2
4 x P 2.5 x P 2.5 x P
d 1
l
2
l 3 l
1 P
Ø’’ d 1 P d 1 l 1 l 2 l 3 d 2 a ID
UNJC TPI mm mm mm mm mm mm
6 32 3.5 56 13 20 4 3 3 2.8 l 199014
8 32 4.16 63 14 21 4.5 3.4 3 3.45 l 199015
10 24 4.82 70 15 25 6 4.9 3 3.9 l 199016
1/4 20 6.35 80 17 30 7 5.5 3 5.2 l 199017

Ø’’ d 1 P d 1 l 1 l 2 l 3 d h6 a ID
2
UNJC TPI mm mm mm mm mm mm
6 32 3.5 56 6.5 20 4 (h9) 3 3 2.8 l 199018
8 32 4.16 63 7.5 21 4.5(h9) 3.4 3 3.45 l 199019
10 24 4.82 70 9 25 6 4.9 3 3.9 l 199020
1/4 20 6.35 80 11 30 6 4.9 3 5.2 l 199021

Ø’’ d 1 P d 1 l 1 l 2 d 2 a ID
UNJC TPI mm mm mm mm mm
6 32 3.5 56 13 4 3 3 2.8 l 199034
8 32 4.16 63 14 4.5 3.4 3 3.45 l 199035
10 24 4.82 70 15 6 4.9 3 3.9 l 199036
1/4 20 6.35 80 20 7 5.5 3 5.2 l 199037
