Page 54 - DC_SWISS(Catalogue_TM_ES-EN)
P. 54
UNJF ISO 3161/ASME B1.15 PM DIN 371
SA320«4 SA350«3 TL351VS«3
SA320-4 15 16 52
SA350-3 15 16 52
R15
< 1.5 x D < 2 x D
TL351VS-3 VS 41 42
R15
< 2 x D
B C C
a
d 2
4 x P 2.5 x P 2.5 x P
d 1
l
2
l 3 l
1 P
Ø’’ d 1 P d 1 l 1 l 2 l 3 d 2 a ID ID ID
UNJF TPI mm mm mm mm mm mm
10 32 4.82 70 15 6 4.9 3 4.1 l 174976 l 188175 l 199042
1/4 28 6.35 80 15 23 7 5.5 3 5.55 l 175993 l 199046 l 199043
5/16 24 7.93 90 18 29 8 6.2 3 7 l 175995 l 199047 l 199044
3/8 24 9.52 100 20 33 10 8 3 8.6 l 175997 l 199048 l 199045
