P. 429
POLY 4001 - 4001-TC
ESCARIADORES P.462 > Ø2.98
DENTADO IRREGULAR RECTO
D nom. D 1 L 1 L 2 D h5 L Z Ref. CARBURO D nom. D 1 L 1 L 2 D h5 L Z Ref. CARBURO
H7 ± 1.5 μm H7 ± 1.5 μm
0.91 (0.917) 5 10 3 38 3 B 200039 1.38 (1.387) 6 13 3 38 3 B 966541
0.92 (0.927) 5 10 3 38 3 B 200035 1.39 (1.397) 6 13 3 38 3 B 960202
0.93 (0.937) 5 10 3 38 3 B 960023 1.40 (1.407) 6 13 3 38 3 B 200050
0.94 (0.947) 5 10 3 38 3 B 963188 1.41 (1.417) 7 15 3 38 3 B 957425
0.95 (0.957) 5 10 3 38 3 B 200034 1.42 (1.427) 7 15 3 38 3 B 955757
0.96 (0.967) 5 10 3 38 3 B 200036 1.43 (1.437) 7 15 3 38 3 B 955746
0.97 (0.977) 5 10 3 38 3 B 200037 1.44 (1.447) 7 15 3 38 3 B 961345
0.98 (0.987) 5 10 3 38 3 B 200032 1.45 (1.457) 7 15 3 38 3 B 200053
0.99 (0.997) 5 10 3 38 3 B 200033 1.46 (1.467) 7 15 3 38 3 B 66791
1.00 (1.007) 5 10 3 38 3 B 200038 1.47 (1.477) 7 15 3 38 3 B 961456
1.01 (1.017) 5 11 3 38 3 B 959800 1.48 (1.487) 7 15 3 38 3 B 200051
1.02 (1.027) 5 11 3 38 3 B 200040 1.49 (1.497) 7 15 3 38 3 B 200052
1.03 (1.037) 5 11 3 38 3 B 966908 1.50 (1.507) 7 15 3 38 3 B 200054
1.04 (1.047) 5 11 3 38 3 B 962626 1.51 (1.517) 7 15 3 50 3 B 200104
1.05 (1.057) 5 11 3 38 3 B 200041 1.52 (1.527) 7 15 3 50 3 B 200105
1.06 (1.067) 5 11 3 38 3 B 966799 1.53 (1.537) 7 15 3 50 3 B 960836
1.07 (1.077) 5 11 3 38 3 B 968047 1.54 (1.547) 7 15 3 50 3 B 63795
1.08 (1.087) 5 11 3 38 3 B 200042 1.55 (1.557) 7 15 3 50 3 B 200125
1.09 (1.097) 5 12 3 38 3 B 955685 1.56 (1.567) 7 15 3 50 3 B 973910
1.10 (1.107) 5 12 3 38 3 B 200045 1.57 (1.577) 7 15 3 50 3 B 963006
1.11 (1.117) 5 12 3 38 3 B 951529 1.58 (1.587) 7 15 3 50 3 B 961472
1.12 (1.127) 5 12 3 38 3 B 951598 1.59 (1.597) 7 15 3 50 3 B 959620
1.13 (1.137) 5 12 3 38 3 B 968503 1.60 (1.607) 7 15 3 50 3 B 200111
1.14 (1.147) 5 12 3 38 3 B 968504 1.61 (1.617) 7 16 3 50 3 B 59391
1.15 (1.157) 5 12 3 38 3 B 200043 1.62 (1.627) 7 16 3 50 3 B 955366
1.16 (1.167) 5 12 3 38 3 B 967147 1.63 (1.637) 7 16 3 50 3 B 326972
1.17 (1.177) 5 12 3 38 3 B 956647 1.64 (1.647) 7 16 3 50 3 B 326973
1.18 (1.187) 5 12 3 38 3 B 67307 1.65 (1.657) 7 16 3 50 3 B 200124
1.19 (1.197) 5 12 3 38 3 B 960753 1.66 (1.667) 7 16 3 50 3 B 991141
1.20 (1.207) 5 12 3 38 3 B 200044 1.67 (1.677) 7 16 3 50 3 B 965451
1.21 (1.217) 6 13 3 38 3 B 67308 1.68 (1.687) 7 16 3 50 3 B 326974
1.22 (1.227) 6 13 3 38 3 B 968605 1.69 (1.697) 7 16 3 50 3 B 952172
1.23 (1.237) 6 13 3 38 3 B 968606 1.70 (1.707) 7 16 3 50 3 B 200126
1.24 (1.247) 6 13 3 38 3 B 968607 1.71 (1.717) 7 17 3 50 3 B 66359
1.25 (1.257) 6 13 3 38 3 B 200046 1.72 (1.727) 7 17 3 50 3 B 959573
1.26 (1.267) 6 13 3 38 3 B 968608 1.73 (1.737) 7 17 3 50 3 B 326975
1.27 (1.277) 6 13 3 38 3 B 964024 1.74 (1.747) 7 17 3 50 3 B 968498
1.28 (1.287) 6 13 3 38 3 B 200048 1.75 (1.757) 7 17 3 50 3 B 200127
1.29 (1.297) 6 13 3 38 3 B 950915 1.76 (1.767) 7 17 3 50 3 B 974605
1.30 (1.307) 6 13 3 38 3 B 200047 1.77 (1.777) 7 17 3 50 3 B 961458
1.31 (1.317) 6 13 3 38 3 B 959472 1.78 (1.787) 7 17 3 50 3 B 63459
1.32 (1.327) 6 13 3 38 3 B 961369 1.79 (1.797) 7 17 3 50 3 B 200146
1.33 (1.337) 6 13 3 38 3 B 961963 1.80 (1.807) 7 17 3 50 3 B 200112
1.34 (1.347) 6 13 3 38 3 B 326971 1.81 (1.817) 8 17 3 50 3 B 962183
1.35 (1.357) 6 13 3 38 3 B 200049 1.82 (1.827) 8 17 3 50 3 B 960953
1.36 (1.367) 6 13 3 38 3 B 968242 1.83 (1.837) 8 17 3 50 3 B 951867
1.37 (1.377) 6 13 3 38 3 B 960591 1.84 (1.847) 8 17 3 50 3 B 326976
