P. 433
POLY 4001 - 4001-TC
ESCARIADORES P.462 > Ø2.98
DENTADO IRREGULAR RECTO
D nom. D 1 L 1 L 2 D h5 L Z Ref. CARBURO D nom. D 1 L 1 L 2 D h5 L Z Ref. CARBURO
H7 ± 1.5 μm H7 ± 1.5 μm
4.67 (4.678) 12 - 4 80 6 A 321371 5.14 (5.148) 12 - 4 80 6 A 321418
4.68 (4.688) 12 - 4 80 6 A 321372 5.15 (5.158) 12 - 4 80 6 A 321419
4.69 (4.698) 12 - 4 80 6 A 321373 5.16 (5.168) 12 - 4 80 6 A 321420
4.70 (4.708) 12 - 4 80 6 A 321374 5.17 (5.178) 12 - 4 80 6 A 321421
4.71 (4.718) 12 - 4 80 6 A 321375 5.18 (5.188) 12 - 4 80 6 A 321422
4.72 (4.728) 12 - 4 80 6 A 321376 5.19 (5.198) 12 - 4 80 6 A 321423
4.73 (4.738) 12 - 4 80 6 A 321377 5.20 (5.208) 12 - 4 80 6 A 321424
4.74 (4.748) 12 - 4 80 6 A 321378 5.21 (5.218) 12 - 4 80 6 A 321425
4.75 (4.758) 12 - 4 80 6 A 321379 5.22 (5.228) 12 - 4 80 6 A 321426
4.76 (4.768) 12 - 4 80 6 A 321380 5.23 (5.238) 12 - 4 80 6 A 321427
4.77 (4.778) 12 - 4 80 6 A 321381 5.24 (5.248) 12 - 4 80 6 A 321428
4.78 (4.788) 12 - 4 80 6 A 321382 5.25 (5.258) 12 - 4 80 6 A 321429
4.79 (4.798) 12 - 4 80 6 A 321383 5.26 (5.268) 12 - 4 80 6 A 321430
4.80 (4.808) 12 - 4 80 6 A 321384 5.27 (5.278) 12 - 4 80 6 A 321431
4.81 (4.818) 12 - 4 80 6 A 321385 5.28 (5.288) 12 - 4 80 6 A 321432
4.82 (4.828) 12 - 4 80 6 A 321386 5.29 (5.298) 12 - 4 80 6 A 321433
4.83 (4.838) 12 - 4 80 6 A 321387 5.30 (5.308) 12 - 4 80 6 A 321434
4.84 (4.848) 12 - 4 80 6 A 321388 5.31 (5.318) 12 - 4 80 6 A 321435
4.85 (4.858) 12 - 4 80 6 A 321389 5.32 (5.328) 12 - 4 80 6 A 321436
4.86 (4.868) 12 - 4 80 6 A 321390 5.33 (5.338) 12 - 4 80 6 A 321437
4.87 (4.878) 12 - 4 80 6 A 321391 5.34 (5.348) 12 - 4 80 6 A 321438
4.88 (4.888) 12 - 4 80 6 A 321392 5.35 (5.358) 12 - 4 80 6 A 321439
4.89 (4.898) 12 - 4 80 6 A 321393 5.36 (5.368) 12 - 4 80 6 A 321440
4.90 (4.908) 12 - 4 80 6 A 321394 5.37 (5.378) 12 - 4 80 6 A 321441
4.91 (4.918) 12 - 4 80 6 A 321395 5.38 (5.388) 12 - 4 80 6 A 321442
4.92 (4.928) 12 - 4 80 6 A 321396 5.39 (5.398) 12 - 4 80 6 A 321443
4.93 (4.938) 12 - 4 80 6 A 321397 5.40 (5.408) 12 - 4 80 6 A 321444
4.94 (4.948) 12 - 4 80 6 A 321398 5.41 (5.418) 12 - 4 80 6 A 321445
4.95 (4.958) 12 - 4 80 6 A 321399 5.42 (5.428) 12 - 4 80 6 A 321446
4.96 (4.968) 12 - 4 80 6 A 321400 5.43 (5.438) 12 - 4 80 6 A 321447
4.97 (4.978) 12 - 4 80 6 A 321401 5.44 (5.448) 12 - 4 80 6 A 321448
4.98 (4.988) 12 - 4 80 6 A 321402 5.45 (5.458) 12 - 4 80 6 A 321449
4.99 (4.998) 12 - 4 80 6 A 321403 5.46 (5.468) 12 - 4 80 6 A 321450
5.00 (5.008) 12 - 4 80 6 A 321404 5.47 (5.478) 12 - 4 80 6 A 321451
5.01 (5.018) 12 - 4 80 6 A 321405 5.48 (5.488) 12 - 4 80 6 A 321452
5.02 (5.028) 12 - 4 80 6 A 321406 5.49 (5.498) 12 - 4 80 6 A 321453
5.03 (5.038) 12 - 4 80 6 A 321407 5.50 (5.508) 12 - 4 80 6 A 321454
5.04 (5.048) 12 - 4 80 6 A 321408 5.51 (5.518) 12 - 4 80 6 A 321455
5.05 (5.058) 12 - 4 80 6 A 321409 5.52 (5.528) 12 - 4 80 6 A 321456
5.06 (5.068) 12 - 4 80 6 A 321410 5.53 (5.538) 12 - 4 80 6 A 321457
5.07 (5.078) 12 - 4 80 6 A 321411 5.54 (5.548) 12 - 4 80 6 A 321458
5.08 (5.088) 12 - 4 80 6 A 321412 5.55 (5.558) 12 - 4 80 6 A 321459
5.09 (5.098) 12 - 4 80 6 A 321413 5.56 (5.568) 12 - 4 80 6 A 321460
5.10 (5.108) 12 - 4 80 6 A 321414 5.57 (5.578) 12 - 4 80 6 A 321461
5.11 (5.118) 12 - 4 80 6 A 321415 5.58 (5.588) 12 - 4 80 6 A 321462
5.12 (5.128) 12 - 4 80 6 A 321416 5.59 (5.598) 12 - 4 80 6 A 321463
5.13 (5.138) 12 - 4 80 6 A 321417 5.60 (5.608) 12 - 4 80 6 A 321464
