Page 434 - DC_SWISS(Catalogue_TM_ES-EN)

POLY 4001 - 4001-TC

ESCARIADORES P.462 > Ø2.98
DENTADO IRREGULAR RECTO

D nom. D 1 L 1 L 2 D h5 L Z Ref. CARBURO D nom. D 1 L 1 L 2 D h5 L Z Ref. CARBURO
H7 ± 1.5 μm H7 ± 1.5 μm

5.61 (5.618) 12 - 4 80 6 A 321465 6.08 (6.090) 12 - 4 80 6 A 321512
5.62 (5.628) 12 - 4 80 6 A 321466 6.09 (6.100) 12 - 4 80 6 A 321513
5.63 (5.638) 12 - 4 80 6 A 321467 6.10 (6.110) 12 - 4 80 6 A 321514
5.64 (5.648) 12 - 4 80 6 A 321468 6.11 (6.120) 12 - 4 80 6 A 321515
5.65 (5.658) 12 - 4 80 6 A 321469 6.12 (6.130) 12 - 4 80 6 A 321516
5.66 (5.668) 12 - 4 80 6 A 321470 6.13 (6.140) 12 - 4 80 6 A 321517
5.67 (5.678) 12 - 4 80 6 A 321471 6.14 (6.150) 12 - 4 80 6 A 321518
5.68 (5.688) 12 - 4 80 6 A 321472 6.15 (6.160) 12 - 4 80 6 A 321519
5.69 (5.698) 12 - 4 80 6 A 321473 6.16 (6.170) 12 - 4 80 6 A 321520
5.70 (5.708) 12 - 4 80 6 A 321474 6.17 (6.180) 12 - 4 80 6 A 321521
5.71 (5.718) 12 - 4 80 6 A 321475 6.18 (6.190) 12 - 4 80 6 A 321522
5.72 (5.728) 12 - 4 80 6 A 321476 6.19 (6.200) 12 - 4 80 6 A 321523
5.73 (5.738) 12 - 4 80 6 A 321477 6.20 (6.210) 16 - 6 101 6 A 341670
5.74 (5.748) 12 - 4 80 6 A 321478 6.30 (6.310) 16 - 6 101 6 A 341680
5.75 (5.758) 12 - 4 80 6 A 321479 6.35 (6.360) 16 - 6 101 6 A 341685
5.76 (5.768) 12 - 4 80 6 A 321480 6.40 (6.410) 16 - 6 101 6 A 341690
5.77 (5.778) 12 - 4 80 6 A 321481 6.48 (6.490) 16 - 6 101 6 A 341698
5.78 (5.788) 12 - 4 80 6 A 321482 6.49 (6.500) 16 - 6 101 6 A 341699
5.79 (5.798) 12 - 4 80 6 A 321483 6.50 (6.510) 16 - 6 101 6 A 341700
5.80 (5.808) 12 - 4 80 6 A 321484 6.51 (6.520) 16 - 6 101 6 A 341701
5.81 (5.818) 12 - 4 80 6 A 321485 6.52 (6.530) 16 - 6 101 6 A 341702
5.82 (5.828) 12 - 4 80 6 A 321486 6.55 (6.560) 16 - 6 101 6 A 341705
5.83 (5.838) 12 - 4 80 6 A 321487 6.60 (6.610) 16 - 6 101 6 A 341710
5.84 (5.848) 12 - 4 80 6 A 321488 6.70 (6.710) 16 - 6 101 6 A 341720
5.85 (5.858) 12 - 4 80 6 A 321489 6.80 (6.810) 16 - 6 101 6 A 341730
5.86 (5.868) 12 - 4 80 6 A 321490 6.90 (6.910) 16 - 6 101 6 A 341740
5.87 (5.878) 12 - 4 80 6 A 321491 7.00 (7.010) 16 - 6 101 6 A 341750
5.88 (5.888) 12 - 4 80 6 A 321492 7.01 (7.020) 16 - 6 101 6 A 341751
5.89 (5.898) 12 - 4 80 6 A 321493 7.02 (7.030) 16 - 6 101 6 A 341752
5.90 (5.908) 12 - 4 80 6 A 321494 7.10 (7.110) 16 - 6 101 6 A 341760
5.91 (5.918) 12 - 4 80 6 A 321495 7.20 (7.210) 16 - 6 101 6 A 341770
5.92 (5.928) 12 - 4 80 6 A 321496 7.30 (7.310) 16 - 6 101 6 A 341780
5.93 (5.938) 12 - 4 80 6 A 321497 7.40 (7.410) 16 - 6 101 6 A 341790
5.94 (5.948) 12 - 4 80 6 A 321498 7.50 (7.510) 16 - 6 101 6 A 341800
5.95 (5.958) 12 - 4 80 6 A 321499 7.60 (7.610) 16 - 6 101 6 A 341810
5.96 (5.968) 12 - 4 80 6 A 321500 7.70 (7.710) 16 - 6 101 6 A 341820
5.97 (5.978) 12 - 4 80 6 A 321501 7.80 (7.810) 16 - 6 101 6 A 341830
5.98 (5.988) 12 - 4 80 6 A 321502 7.90 (7.910) 16 - 6 101 6 A 341840
5.99 (5.998) 12 - 4 80 6 A 321503 7.98 (7.990) 16 - 6 101 6 A 341848
6.00 (6.008) 12 - 4 80 6 A 321504 7.99 (8.000) 16 - 6 101 6 A 341849
6.01 (6.020) 12 - 4 80 6 A 321505 8.00 (8.010) 16 - 6 101 6 A 341850
6.02 (6.030) 12 - 4 80 6 A 321506 8.01 (8.020) 16 - 6 101 6 A 341851
6.03 (6.040) 12 - 4 80 6 A 321507 8.02 (8.030) 16 - 6 101 6 A 341852
6.04 (6.050) 12 - 4 80 6 A 321508 8.05 (8.060) 16 - 6 101 6 A 341855
6.05 (6.060) 12 - 4 80 6 A 321509 8.10 (8.110) 16 - 6 101 6 A 420538
6.06 (6.070) 12 - 4 80 6 A 321510 8.20 (8.210) 16 - 8 117 6 A 420539
6.07 (6.080) 12 - 4 80 6 A 321511 8.30 (8.310) 16 - 8 117 6 A 420540
