P. 44
a p
v c
a e
f z
d 1
v f
n
Q
Application Material [mm] z [m/min] [mm] [mm] [mm] [min ] -1 [mm/min] [cm /min]
3
Nickel-based alloys 6.00 5 45 0.020 10.800 1.200 2385 239 3.1
annealed 8.00 5 45 0.030 14.400 1.600 1790 269 6.2
Rm <1000 N/mm² 10.00 5 45 0.035 18.000 2.000 1430 250 9.0
[Inconel 718] 12.00 5 45 0.045 21.600 2.400 1195 269 13.9
16.00 5 45 0.050 28.800 3.200 895 224 20.6
20.00 5 45 0.060 36.000 4.000 715 215 30.9
Nickel-based alloys 6.00 5 30 0.015 10.800 1.200 1590 119 1.5
precipitation hardened 8.00 5 30 0.025 14.400 1.600 1195 149 3.4
Rm > 1000 N/mm² 10.00 5 30 0.030 18.000 2.000 955 143 5.2
[Inconel 718] 12.00 5 30 0.035 21.600 2.400 795 139 7.2
16.00 5 30 0.040 28.800 3.200 595 119 11.0
20.00 5 30 0.050 36.000 4.000 475 119 17.1
Manganese steel 6.00 5 50 0.020 10.800 1.200 2655 266 3.4
Mn >5% 8.00 5 50 0.030 14.400 1.600 1990 299 6.9
[1.3964 / Nitronic] 10.00 5 50 0.035 18.000 2.000 1590 278 10.0
[1.3401 / X120Mn12] 12.00 5 50 0.045 21.600 2.400 1325 298 15.5
16.00 5 50 0.050 28.800 3.200 995 249 22.9
20.00 5 50 0.060 36.000 4.000 795 239 34.3
Inox difficult 6.00 5 60 0.035 10.800 1.200 3185 557 7.2
[Cr-Ni-Mo++/1.4529] 8.00 5 60 0.045 14.400 1.600 2385 537 12.4
Heat resistant steel 10.00 5 60 0.055 18.000 2.000 1910 525 18.9
[1.4841] 12.00 5 60 0.065 21.600 2.400 1590 517 26.8
16.00 5 60 0.070 28.800 3.200 1195 418 38.6
20.00 5 60 0.085 36.000 4.000 955 406 58.4
PM high-speed steel 6.00 5 90 0.020 10.800 1.200 4775 478 6.2
annealed 8.00 5 90 0.030 14.400 1.600 3580 537 12.4
[Böhler S390] 10.00 5 90 0.035 18.000 2.000 2865 501 18.1
[ASP 2023] 12.00 5 90 0.045 21.600 2.400 2385 537 27.8
16.00 5 90 0.050 28.800 3.200 1790 448 41.2
20.00 5 90 0.060 36.000 4.000 1430 429 61.8
Titanium alloys 6.00 5 85 0.020 10.800 1.200 4510 451 5.8
> 300 HB 8.00 5 85 0.025 14.400 1.600 3380 423 9.7
[Ti6Al4V] 10.00 5 85 0.035 18.000 2.000 2705 473 17.0
12.00 5 85 0.040 21.600 2.400 2255 451 23.4
16.00 5 85 0.045 28.800 3.200 1690 380 35.0
20.00 5 85 0.055 36.000 4.000 1355 373 53.7
