Page 753 - 21-036 APPLITEC catalogue.indb

Forward and reverse deburring end mills

45° - Chamfer

h ƍ
a ƍ

GG(G)
Rm Rm Rm Inox Ti Aluminium
< 850 850-1100 1100-1300 Stainless Titanium
Copper
UNICUT-4X
Coating Article-N°. ø-Code
Example:
Order-N°. U 7930 180
U7930
Ø d 1 d 2 α
Code 0/-0.05 h6 d 3 d 5 l 1 l 2 l 3 l 4 l 8 z
180 3.00 6.00 2.20 1.2 100 1.30 10.00 60.00 1.27 90.0° 4 •
220 4.00 6.00 2.90 1.6 100 1.75 12.00 60.00 1.70 90.0° 4 • V
260 5.00 6.00 3.40 2.0 100 2.30 15.00 60.00 2.12 90.0° 4 •
300 6.00 6.00 3.80 2.4 100 2.90 18.00 60.00 2.55 90.0° 4 •
391 8.00 6.00 4.90 4.9 100 3.10 35.00 60.00 2.19 90.0° 4 •
450 10.00 6.00 5.90 5.9 100 4.10 35.00 60.00 2.90 90.0° 4 •
501 12.00 6.00 5.90 5.9 100 6.10 35.00 60.00 4.31 90.0° 4 •

fraisa.com
751
