Page 281 - Carbide drills I Thread cutting tools 2023

Taps

M
GG(G)
Rm Inox Aluminium
< 850 Stainless Copper

Article-N°. ø-Code
Example: E10214
Order-N°. E10214 034
Ø
Code d P L l l 1 l 3 d 2 a
034 M 2 0.40 45 8.00 - 10.5 2.8 2.1 3 –0.014 •
040 M 2.5 0.45 50 9.00 - 13.0 2.8 2.1 3 –0.015 •
044 M 3 0.50 56 4.00 18.0 16.0 3.5 2.7 3 –0.016 •
058 M 4 0.70 63 5.60 21.0 19.0 4.5 3.4 3 –0.019 •
084 M 5 0.80 70 6.40 25.0 23.0 6.0 4.9 3 –0.020 •
088 M 6 1.00 80 8.00 30.0 28.0 6.0 4.9 3 –0.024 •
160 M 8 1.25 90 10.00 35.0 33.0 8.0 6.2 3 –0.025 •
174 M 10 1.50 100 12.00 39.0 37.0 10.0 8.0 3 –0.028 •

fraisa.com
279
