Page 342 - Carbide drills I Thread cutting tools 2023

v f
v c
n
v c
d
P
v f
n
v c
n
v f
Application Material M [mm] [mm] 1.5 x d [min ] -1 [100%] 2.0 x d [min ] -1 [100%] 3.0 x d [min ] -1 [100%]
Steel M 12 12.000 1.75 20 530 928 15 400 700 10 265 464
< 850 N/mm 2 M 14 14.000 2.00 20 455 910 15 340 680 10 225 450
A 5 > 10% M 16 16.000 2.00 20 400 800 15 300 600 10 200 400
Steel M 12 12.000 1.75 15 400 700 10 265 464 - - -
850 - 1100 N/mm 2 M 14 14.000 2.00 15 340 680 10 225 450 - - -
A 5 > 10% M 16 16.000 2.00 15 300 600 10 200 400 - - -
Stainless steel M 12 12.000 1.75 15 400 700 10 265 464 - - -
ferritc/martensitic M 14 14.000 2.00 15 340 680 10 225 450 - - -
A 5 > 10% M 16 16.000 2.00 15 300 600 10 200 400 - - -

Stainless steel M 12 12.000 1.75 15 400 700 10 265 464 - - -
[Cr-Ni/1.4301] M 14 14.000 2.00 15 340 680 10 225 450 - - -
M 16 16.000 2.00 15 300 600 10 200 400 - - -

fraisa.com
340
