Series 220R, 223R, 230R, 820R, 823R, 830R (continued)

.6299" - 1.000"
(16.000mm - 25.400mm)
GENERAL PURPOSE END MILLS (220R/820R) (223R/823R) (230R/830R) d1 † d2 l1 l2 r

2 Flute
Flute
Shank
EDP#
EDP#
EDP#
Length
Metric
Radius
.6299
16.0
88
36272
36590
24450
38
0.50
88
.6299
16.000
24460
38
36592 3 Flute 4 Flute Decimal Diameter 16.000 Diameter Overall Length Corner
1.00
36274
16.0
36594 36276 24470 .6299 16.000 16.0 88 38 2.00
36596 36278 24480 .6299 16.000 16.0 88 38 2.50
36598 36280 24490 .6299 16.000 16.0 88 38 3.00
36600 36282 24500 .6299 16.000 16.0 88 38 4.00
36602 36284 24510 .6299 16.000 16.0 88 38 5.00
79440 36286 80440 .7500 3/4" 19.050 3/4" 4" 1-1/2" .015"
79450 36288 80450 .7500 3/4" 19.050 3/4" 4" 1-1/2" .020"
79460 36290 80460 .7500 3/4" 19.050 3/4" 4" 1-1/2" .030"
79470 36292 80470 .7500 3/4" 19.050 3/4" 4" 1-1/2" .045"
70
79480 36294 80480 .7500 3/4" 19.050 3/4" 4" 1-1/2" .060"
6
79490 36296 80490 .7500 3/4" 19.050 3/4" 4" 1-1/2" .090"
79500 36298 80500 .7500 3/4" 19.050 3/4" 4" 1-1/2" .125"
79630 36300 80630 .7500 3/4" 19.050 3/4" 4" 1-1/2" .250"
36604 36302 24520 .7874 20.000 20.0 100 38 0.50
36606 36304 24530 .7874 20.000 20.0 100 38 1.00
36608 36306 24540 .7874 20.000 20.0 100 38 2.00
36610 36308 24550 .7874 20.000 20.0 100 38 3.00
36612 36310 24560 .7874 20.000 20.0 100 38 5.00
79510 36312 80510 1.000 1" 25.400 1" 4" 1-1/2" .015"
79520 36314 80520 1.000 1" 25.400 1" 4" 1-1/2" .020"
79530 36316 80530 1.000 1" 25.400 1" 4" 1-1/2" .030"
79540 36318 80540 1.000 1" 25.400 1" 4" 1-1/2" .045"
79550 36320 80550 1.000 1" 25.400 1" 4" 1-1/2" .060"
79560 36322 80560 1.000 1" 25.400 1" 4" 1-1/2" .090"
79570 36324 80570 1.000 1" 25.400 1" 4" 1-1/2" .125"
79640 36326 80640 1.000 1" 25.400 1" 4" 1-1/2" .250"
35
6
MATERIAL HARDNESS (Rc)

0
6
