USER GUIDE
ENDMILLS • SOLID CARBIDE • MULTI-MASTER
Circle Segment Lines for Advanced Finish Milling Operations
Barrel Endmill
ISCAR’s Barrel line comprises a variety of solid carbide
endmills and MULTI-MASTER heads in different shapes:
Oval, Taper & Lens.
For more information, refer to NPA 22-2020
Solid Carbide Endmills
Oval Barrel – EOB
Taper Barrel – ETB
Lens Barrel – ELB
MULTI-MASTER Heads
Oval Barrel – MM EOB
Lens Barrel – MM ELB
Barrel endmills are intended for finish and
semi-finish machining of 3D surfaces
Blade Rough Blade Finish
A prominent advantage of a Barrel endmill over a
Ball-Nose is the number of stepovers and, subsequent,
machining time can be significantly reduced without
degradation of the surface finish parameters.
The large-diameter arc of the endmill cutting edge
results in a substantial reduction of the cusp height.
