PROFILING TOOLS FRN DCX (1) 37.30 APMX 40.00 DCONMS DHUB DHUB STDLET APMX 5 6 7 OAL MDN (3) MDX (4) RMPX° (5) Rd° kg
DCONMS
Face Mill for Wedge-Clamped
Double-Sided Round Insert

DC
DCX

(2)
CICT
DC
OAL
Designation
FRN D038A050-05-22-12
45.00
99.00
0.4
0.46
22.00
A
3.00
87.30
50.00
FRN D051A063-06-22-12
63.00
50.30
0.63
3.00
40.00
125.00
A
113.30
47.00
0.3
22.00
159.00
80.00
147.30
3.00
50.00
27.00
67.30
A
58.00
0.3
FRN D068A080-07-27-12
0.85
• Radius for programing: 6.35
(1) Cutting diameter maximum
(2) Number of inserts
(3) For interpolation
(4) For interpolation
(5) Maximum ramping angle
For inserts, see pages: RNGN-Ceramic (531)

Spare Parts
Designation
FRN WEDGE SCREW (a) LW 1207C T-W3
(a) Recommended tightening torque:4.8 Nm
DHUB
DCONMS Rd°

FRMT
Face Mills for Productive
Machining of 3D Surfaces of OAL
Blades in Turbomachinery RE
APMX
DC
DCX
Designation DCX (1) DC RE APMX CICT (2) OAL DCONMS RMPX° (3) Arbor (4) DHUB MIID (5) kg
FRMT D030A040-05-16-10 40.00 30.00 5.00 3.10 5 40.00 16.00 1.0 A 38.00 RP...X 1003M0 ... 0.20
FRMT D028A040-04-16-12 40.00 28.00 6.00 3.80 4 40.00 16.00 1.0 A 38.00 RP...X 1204M0 ... 0.20
FRMT D038A050-05-22-12 50.00 38.00 6.00 3.80 5 40.00 22.00 2.5 A 48.00 RP...X 1204M0 ... 0.29
FRMT D038A050-06-22-12 50.00 38.00 6.00 3.80 6 40.00 22.00 1.0 A 48.00 RP...X 1204M0 ... 0.29
FRMT D040A052-05-22-12 52.00 40.00 6.00 3.80 5 40.00 22.00 2.5 A 48.00 RP...X 1204M0 ... 0.31
FRMT D040A052-06-22-12 52.00 40.00 6.00 3.80 6 40.00 22.00 1.0 A 48.00 RP...X 1204M0 ... 0.30
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation see page 548
(5) Insert identification
For inserts, see pages: RPHX/RPMX (530)
Spare Parts
Designation
FRMT D030A040-05-16-10 SR 10504970 SW6-SD BLD IP15/S7
FRMT D028A040-04-16-12 SR 76-2067 SW6-T BLD T15/S7
FRMT D038A050-05-22-12 SR 76-2067 SW6-T BLD T15/S7
FRMT D038A050-06-22-12 SR 76-2067 SW6-T BLD T15/S7
FRMT D040A052-05-22-12 SR 76-2067 SW6-T BLD T15/S7
FRMT D040A052-06-22-12 SR 76-2067 SW6-T BLD T15/S7

278 ISCAR
